Quick Detail:
○ Low power consumption, high reliability;
○ 12 years production experience in SMPS;
○ 100% full loading burn-in test;
○ 3 senior engineers with over 15 years experience in this field
○ Protections: Short-circuit/Over load/Over voltage
○ All products have been checked and packaged in good condition before dispatch
12V 30A Technical Specification |
| Model No. | SPMS-360-12 |
| Input | Voltage | AC 100-240V Worldwide |
| Vibration Input Voltage Range | AC 95-265V |
| Frequency | 50-60Hz |
| Output | Voltage | DC 12V |
| Current | 30A |
| Power | 360W |
| Typical Efficiency | 85% |
| Adjustable Range of Voltage | DC 12V-12.5V |
| Max. Ripple & Noise | 250mV |
| Protection | Over Load | 105-115% of Rated Output Power |
| Short Circuit | Protection Type: Auto Recovery |
| Electric Strength | High-pot test | 3KV AC |
| Environment | Working temperature and humidity | -10°C~+60°C,20~90%RH |
| Store temperature and humidity | 20°C~+85°C,10~95%RH |
| MTBF | >200K hrs.@25°C(MIL-HDBK-217F) |
| Warranty | 2 years |
| Feature | Dimension(L*W*H) | 213*112*49 mm |
| Weight | 760g |
| Inner box size | 118*55*220 mm |
| Inner box weight | 14g |
| PCS/CTN | 36PCS/CTN |
| CTN size | 54*26*45 cm |
| GW/CTN | 30 kg |
| Safety & EMC | Safety Standards | EN55015/EN61000-3-2/EN61000-3-3 |
Competitive Advantages:
1. Factory outlet: Wholesale discounts & good quality
2. Timely delivery : 1-7 business days (depends on quantity)
3. Certification: Our products are mostly certified by CE, LVD, RoHS, EMC, FCC
4. OEM and ODM Service: Customized power supply accepted within 1200W
5. High quality PCB
6. Full capacity
7. More stable working condition
8. Strong heat spreading performance with fan
9. 100% raw materials testing
10. Good service: Your inquiry related to our products or prices will be replied in 24 hours. Well-trained and experienced staffs to answer all your enquires in fluent English.
Applications:
1. Digital and electronic products
2. 3D Printer
3. Fiber transceivers, game player, LED, CCTV camera
4. Electrical equipment, Instrumentation
5. Industrail equipment
6. Communications and security products;
7. LED Strip Lighting/ LED lamp / LED Lights
8. LED Display, etc.
Packaging & Shipping
Our power supply package: Each power supply in one white gife box; 100 boxes to a carton; Customization Accepted
Delivery Detail: usually 3-5 working days also depend on order quantity.
Payment
- We accept T/T, Western Union, Paypal before production
- If buyers have any problems about payment, please feel free to contact us
FAQ
Q1: what is the warranty for high quality power supply?
A1: For the power adapter,we have 1 year warranty,Any quality problem happened in this period of time for our reason,we will send the replacement parts in next order.
Q2:How soon can I get samples for test to check quality?
A2:After price confirmed,for our normal products(not customized products),we can send samples for you in 1-2 days.And our samples usually not for free,After large order placed samples costs can be refundable.
Q3:what is your defective rate for high quality power supply?
A3:The defective rate for our high quality power adapter is about 0.3%~0.5%.
Q4: Can you accept OEM&ODM service business?
A4:yes,we can. We can customize the products,labels,package as your demands.
Q5:What's your payment terms?
A5:Standard terms: T/T in advance. Large amount: L/C at sight. Small amount like sample fees: Paypal and Western Union.
Q6:What about delivery time?
A6:in 24 hours for 1-1,000PCS. in 72 hours for 1,000-5,000PCS. in 5 days for 5,000-20,000PCS. in 1 week for above 20,000PCS.
Q7:How do you usually ship the goods?
A7:For small order,by express.For large order,If you need urgently,by air,and also can by sea,but take much time.But we promise to find the most economic and safe way to delivery the goods for you.
DONGGUAN SUPERPOWER SUPPLY Co., Ltd, which creates in 2001, is a private high-tech enterprise. Our company is specializing in the design, development, production and sales of LED switching power supply, water-proof power supply, rain-proof power supply, CCTV power supply, power adapter, rail power supply, etc. Company's registered capital is 5 million RMB, plant area over 2000 square meters. Company has a series of advanced production and testing equipment, such as automatic lead-free baptist tin stoves, automatic shear pin machine, full automatic wave crest solder, reflow soldering, etc., with an annual output of various types of power supplies up to 1 million units. The products are widely used in LED lighting engineering, security monitoring, automation equipment, etc...
Our company adhere to the path of industrial science and technology, and constantly develop new products, open up new markets, now the products have sell well all over the country, even exported to Southeast Asia, the Middle East, Europe and the United States and African countries. Company adhere to the "people-oriented, winning with quality, honesty and trustworthiness, common development" business philosophy, adhere to the "take the customer as the center" to expand the market, we sincerely wish to establish good strategic partnership with you, with our professional level, excellent quality, reasonable price and quality service to become your best partner. We sincerely welcome new and old customers at home and abroad to guide and create a great cause of development for SUPERPOWER SUPPLY.
