12V 80 Ah Deep Cycle AGM Golf Cart Solar Power Emergency Battery
Price: |
US $ 65/Piece |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,D/P |
Prod Model: |
GE80-12V |
Type: |
Lead-Acid Batteries |
Usage: |
Solar Power |
Nominal Voltage: |
12V |
Discharge Rate: |
Medium Discharge Rate |
Shape: |
Square Battery |
Rechargeable: |
Chargeable |
Product Description
Deep Cycle AGM battery is specially designed for the deep cycle discharge applications. It means the depth of discharge of DC series is more than 60 per cent of the rated capacity. Deep cycle series products have large storage capacity, adopting special paste formula and grid alloy meet the repeated charge discharge cycle (deep cycle) characteristics. Hard deep cycle battery using thick plate and super deep electrolyte to ensure longer life cycle. The series batteries are applied to the equipment require frequently deep discharge from batteries.
Advantages
1. Design life: 12 years(25ºC);
2. EUROBAT Classification: Long life;
3. High discharge performance;
4. 99%+ gas recombination efficiency;
5. Maximum charge efficiency;
6. Low self-discharge rate;
7. Easy installation and handling;
Product Standards
You can expect our batteries meet with the standards JIS, DIN, IEC60896-21/22. We have obtained ISO9001 & ISO14001 certification..
GB/T19638.1-2014
YD/T799-2010
DL/T637-1997
JIS C8704-1:2006
JIS C8704-2:2006
IEC60896-21/22:2004
Eurobat guide
Installation compliant with EN50272-2
General Features
1. Using oxygen recombination technology: maintenance-free
2. Special grid alloy: less gassing, less self-discharging
3. For longer cycle life: special paste formula, manufacturing process optimization, additives for deep discharge
4. High quality AGM separator: extend cycle life and prevent micro short circuit
5. ABS material: increase the strength of battery container. (Flame-retardant ABS is optional)
6. Safe and leak free.
7. higher charging acceptance.
Typical Applications
1. Electric tools
2.Vehicle in place of walking
3. Wheelchairs
4. Golf trolleys and golf cart
5. Medical equipment
6. Electric toys
7. Illumination light
8. Fire alarms
9. Portable power
10. Portable apparatus, lights and instruments;
11. Medical equipment
Deep Cycle Series Sealed Rechargeable Lead-Acid Batteries |
Model | Nominal Voltage(V) | Rated Capacity@25ºC(AH) | Approx Dimensions | Approx Weight | Terminals Type | Layout |
20HR 1.75V/Cell | Length | Width | Hight | Total Hight |
mm | in. | mm | in. | mm | in. | mm | in. | kgs. | lbs. |
GE150-6DC | 6 | 150 | 306 | 12.05 | 168 | 6.61 | 220 | 8.66 | 225 | 8.86 | 26 | 57.32 | G | 5 |
GE180-6DC | 6 | 180 | 306 | 12.05 | 168 | 6.61 | 220 | 8.66 | 225 | 8.86 | 28 | 61.73 | G | 5 |
GE200-6DC | 6 | 200 | 306 | 12.05 | 168 | 6.61 | 220 | 8.66 | 225 | 8.86 | 30.5 | 67.24 | G | 6 |
GE210-6DC | 6 | 210 | 260 | 10.24 | 180 | 7.09 | 247 | 9.72 | 251 | 9.88 | 29.5 | 65.04 | G | 6 |
GE220-6DC | 6 | 220 | 306 | 12.05 | 168 | 6.61 | 220 | 8.66 | 225 | 8.86 | 32 | 70.55 | G | 6 |
GE225-6DC | 6 | 225 | 244 | 9.61 | 190 | 7.48 | 275 | 10.83 | 275 | 10.83 | 31 | 68.34 | G | 6 |
GE310-6DC | 6 | 310 | 295 | 11.61 | 178 | 7.01 | 345 | 13.58 | 350 | 13.78 | 45.6 | 100.53 | G | 5 |
GE325-6DC | 6 | 325 | 295 | 11.61 | 178 | 7.01 | 345 | 13.58 | 350 | 13.78 | 48 | 105.82 | G | 6 |
GE380-6DC | 6 | 380 | 295 | 11.61 | 178 | 7.01 | 404 | 15.91 | 410 | 16.14 | 55.3 | 121.91 | G | 6 |
GE400-6DC | 6 | 400 | 295 | 11.61 | 178 | 7.01 | 404 | 15.91 | 410 | 16.14 | 59.8 | 131.84 | G | 6 |
GE450-6DC | 6 | 450 | 295 | 11.61 | 178 | 7.01 | 404 | 15.91 | 410 | 16.14 | 64.3 | 141.76 | G | 6 |
GE200-8DC | 8 | 200 | 260 | 10.24 | 182 | 7.17 | 295 | 11.61 | 301 | 11.85 | 39.5 | 87.08 | G | 6 |
GE14-12DC | 12 | 14 | 151 | 5.94 | 99 | 3.90 | 96 | 3.78 | 102 | 4.02 | 4.4 | 9.70 | B | 4 |
GE17-12DC | 12 | 17 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.57 | 6.2 | 13.67 | C | 2 |
GE24-12DC | 12 | 24 | 166 | 6.54 | 175 | 6.89 | 126 | 4.96 | 126 | 4.96 | 8.2 | 18.08 | E | 2 |
GE26-12DC | 12 | 26 | 165 | 6.50 | 129 | 5.08 | 174 | 6.85 | 174 | 6.85 | 9.5 | 20.94 | F | 2 |
GE28-12DC | 12 | 28 | 165 | 6.50 | 129 | 5.08 | 174 | 6.85 | 174 | 6.85 | 10 | 22.05 | F | 2 |
GE35-12DC | 12 | 35 | 196 | 7.72 | 131 | 5.16 | 155 | 6.10 | 167 | 6.57 | 10.5 | 23.15 | F | 2 |
GE40-12DC | 12 | 40 | 198 | 7.80 | 166 | 6.54 | 174 | 6.85 | 174 | 6.85 | 13 | 28.66 | F | 2 |
GE55-12DC | 12 | 55 | 228 | 8.98 | 138 | 5.43 | 208 | 8.19 | 227 | 8.94 | 17.8 | 39.24 | F | 2 |
GE60-12DC | 12 | 60 | 228 | 8.98 | 138 | 5.43 | 208 | 8.19 | 227 | 8.94 | 20.7 | 45.64 | F | 1 |
GE70-12DC | 12 | 70 | 350 | 13.78 | 168 | 6.61 | 178 | 7.01 | 178 | 7.01 | 23.5 | 51.81 | F | 1 |
GE75-12DC | 12 | 75 | 266 | 10.47 | 169 | 6.65 | 211 | 8.31 | 215 | 8.46 | 25 | 55.12 | F | 1 |
GE85-12DC | 12 | 85 | 266 | 10.47 | 169 | 6.65 | 211 | 8.31 | 215 | 8.46 | 26 | 57.32 | F | 1 |
GE90-12DC | 12 | 90 | 307 | 12.09 | 169 | 6.65 | 211 | 8.31 | 216 | 8.50 | 28 | 61.73 | F | 1 |
GE100-12DC | 12 | 100 | 307 | 12.09 | 169 | 6.65 | 211 | 8.31 | 216 | 8.50 | 30 | 66.14 | F | 1 |
GE110-12DC | 12 | 110 | 329 | 12.95 | 172 | 6.77 | 214 | 8.43 | 220 | 8.66 | 32.5 | 71.65 | F | 1 |
GE120-12DC | 12 | 120 | 407 | 16.02 | 175 | 6.89 | 210 | 8.27 | 233 | 9.17 | 38 | 83.77 | G | 1 |
GE135-12DC | 12 | 135 | 341 | 13.43 | 173 | 6.81 | 281 | 11.06 | 288 | 11.34 | 42.3 | 93.25 | G | 1 |
GE150-12DC | 12 | 150 | 483 | 19.02 | 170 | 6.69 | 241 | 9.49 | 241 | 9.49 | 45.5 | 100.31 | G | 1 |
GE180-12DC | 12 | 180 | 532 | 20.94 | 206 | 8.11 | 216 | 8.50 | 222 | 8.74 | 56 | 123.46 | G | 3 |
GE200-12DC | 12 | 200 | 532 | 20.94 | 206 | 8.11 | 216 | 8.50 | 222 | 8.74 | 59 | 130.07 | G | 3 |
GE210-12DC | 12 | 210 | 522 | 20.55 | 240 | 9.45 | 218 | 8.58 | 244 | 9.61 | 65 | 143.30 | G | 3 |
GE240-12DC | 12 | 240 | 520 | 20.47 | 269 | 10.59 | 203 | 7.99 | 209 | 8.23 | 70.3 | 154.98 | G | 3 |
GE260-12DC | 12 | 260 | 520 | 20.47 | 269 | 10.59 | 220 | 8.66 | 209 | 8.23 | 77 | 169.75 | G | 3 |
GE300-12DC | 12 | 300 | 522 | 20.55 | 269 | 10.59 | 220 | 8.66 | 226 | 8.90 | 90.4 | 199.30 | G | 3 |
Guangdong JIYI General Electric Co. Ltd started in 1986, originated from American lead acid battery company BHNGE BATTERIES Ltd. We are the earliest company who obtained American technology of VRLA, and we are the only one manufacturer of GERCH brand VRLA battery. Guangdong JIYI invested RMB200, 000, 000 to build factories in China, a manufacture base of 190, 000 square meters. With the development of GERCH brand, we are going deeper and deeper into international market, providing lead acid batteries in high quality and good price.
Guangdong JIYI General Electric Co. Ltd is the first battery company certified with the ISO9001 quality system in 1996. We also got certification of CE and UL (first one in battery industry in China) in 1997, and become the member of American Battery Industry Association in 1999 (only one in China). In 2003 GERCH was ranked international famous brand, the first one in China, and at the same time we got certification of IEC, the only one member from China.
Guangdong JIYI General Electric Co. Ltd imported full set of equipment from America and Germany, set test and research center. We are equipped with German test device "BAIRD"spectrometer, shaking test machine, universal battery test device, high current discharging test machine and other equipment. Our quality monitoring is on each step of production, raw material, semi-product and final product. The application of our battery covers many industries such as aviation, ship, military, plant, transformer, solar system, UPS, EPS, telecommunication, medical device, meters, engine, vehicle, truck and power tool etc.
Our company philosophy is work in scientific way, provide high quality product, satisfy customer and environment friend. Each of our products will strictly be built complying with domestic and international standard, and will be inspected by authorized organization.
Guangdong JIYI General Electric Co. Ltd produce all series of lead acid battery covering 1) Nano battery, 2)Silicon energy battery, 3)Lead crystal battery, 4)Deep cycle solar battery, 5)Gel solar battery, 6)GFM VRLA fattery, 7)Deep cycle motive battery, 8)OPzS battery, 9)OPzV maintenance free battery, 10)battery for boat, 11)Long life battery, 12)BS & DIN standard motive battery, 13)Aviation, nuclear station and rare earth battery, 14)High rate battery, 15)Lead carbon battery, 16)Polymer battery. Other relative products include 1)UPS, 2)solar panel, inverter, 3)DC system, 4)recharge device, 5)charging equipment, 6)monitor, 7)battery box. Our annual capacity is up to 1.20 million KVAH, one of the biggest production capacity in China.
Guangdong JIYI General Electric Co. Ltd we have a large group of respectable customer from all over the world. We are shipping to European countries, America, Australia, Africa, Japan, South Korea, Middle East, South east Asia market. We cooperate with GE, China aviation department, China military, State grid, Nuclear power station, hydro power station, BAO steel group, HUAWEI, Delix, National bank, ship manufacturing group etc.
