20 AMP, 125 Volt, NEMA 5-20p, Straight Blade Plug

Name: 20 AMP, 125 Volt, NEMA 5-20p, Straight Blade Plug
Brand: all-electronics-online.com
SKU: 689560592
Availability: InStock
Rating: 4.5 (127 reviews)

Price:	US $ 0.45/Piece
Trade Terms:	FOB
Min Order:	5000/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

SPECIFICATIONS
· Part No.: JCT001B
· Description: 20 Amp, 125 Volt, NEMA 5-20P, 2P, 3W, Plug, Straight Blade, Grounding
· Color: Black
· Rating: 20A, 125VAC
· NEMA: 5-20P
· Pole: 2
· Wire: 3
· Dielectric Voltage: Withstands 2000V per UL498
· Housing: Thermoplastic Nylon
· Blades/Contacts: Brass

CODE COMPLIANCE
· UL 498 comply
· ROHS comply

MATERIAL CHARACTERISTICS
· Environmental: Flammability, UL-94, Rated V0
· Operating Temperature: -40° F to 149° F (-40° C to 65° C)

FEATURES
· Solid brass plug blades are firmly embedded in body
· Terminal screw clamp are designed to contain wire and prevent binding
· Terminal screws backed out-ready for wiring
· Terminals in individual chambers to positively insulate conductors
· Armored housing automaticaly grounded
· Limited Two-Year Warranty

Prod Model:	JCT001B
Markets:	North America,South America,Mid East
NEMA:	5-20p
Standard:	American Standard
Function:	AC Plug

Lumex is a specialized manufacturer of custom and standard electrical wiring devices, Founded in 1997, Lumex offers nearly 18 years of proven performance in producing superior quality products.

Quality is the founding principal of Lumex' manufacturing philosophy. Lumex is certified ISO 9001: 2008, Most of the electrical wiring devices in Lumex are UL, ETL and RoHS approved. All our products are 100% quality guaranteed.

Lumex incorporates the most advanced design and manufacturing technologies. All Lumex's products have been designed and prototyped for sales using the most advanced testing techniques and methods.

In nearly 18 years, Lumex has invested the most modern manufacturing technology and equipments, and as a result, we have consistently provided large OEMs with the most cost effective alternatives globally.

Customer Satisfaction, Design Engineering, Quality, and On-Time Delivery are four key areas we are focusing on to insure high quality electrical wiring devices and total customer satisfaction. Our partner companies rely upon us to create superior quality, budget conscious solutions for complex challenges. At Lumex, we view solutions as the key to our continued growth and success.
