Off Grid Hybrid Pure Sine Wave Inverter Controller Rainbow Star Plus Series 1000Va-5000Va (1ph in/1ph out)
Key Features
1: Advanced microprocessor control
2: Built-in PWM solar charge controller
3: Designed to Operate under Harsh Environment
4: Professional solution for Off-Grid solar system
5: Compatible to mains voltage or generator power
6: Multiple communication for USB ,RS232 and SNMP
7: Configurable AC/Solar input priority via LCD setting
8: Efficient up 3~5% than traditional power frequency inverter
9: High E fficiency Design & "Power Saving Mode" to Conserve Energy
10: LED & LCD Display on the front panel shows the working and failure state
11: Parallel operation with up to 4units only available for 4KVA/5KVA (Optional)
12: Selectable input voltage range for home appliances and personal computers
Application
Supply the reliable long back up time power for the TV, Control equipment,Computer,DVD,Communications Equipment,VCD, Printing machines,Data center,laptop,Lighting equipment,etc.
220VAC 50HZ Inverter with Advanced microprocessor control Specification
| Technical Specification |
| Model | RS Plus 1K | RS Plus 2K | RS Plus 3K | RS Plus 4K | RS Plus 5K |
| RATED POWER | 1000VA/800W | 2000VA/1600W | 3000VA/2400W | 4000VA/3200W | 5000VA/4000W |
| INPUT |
| Voltage | 208/220/230/240 VAC |
Selectable
Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| OUTPUT |
AC Voltage Regulation
(Batt. Mode) | 230 VAC ± 5% |
| Surge Power | 2000VA | 4000VA | 6000VA | 8000VA | 10000VA |
| Efficiency (Peak) | 90~93% | 93% |
| Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| BATTERY & AC Charger |
| Battery Voltage | 12VDC | 24VDC | 48 VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC | 54 VDC |
| Overcharge Protection | 15.5VDC | 30VDC | 60 VDC |
Maximum AC
Charge Current | 10A or 20A | 20A or 30A | 20A or 30A |
| SOLAR CHARGER |
Maximum PV Array
Open Circuit Voltage | 30VDC | 60VDC | 90VDC |
| Solar Charge Current | 50A | 110A |
Standby Power
Consumption | 1W | 2W | 2W |
| PHYSICAL |
| Dimension, D x W x H (mm) | 95*240*316 | 100*272*355 | 120*295*468 |
| Net Weight (kgs) | 5 | 6.4 | 6.9 | 9.8 | 9.8 |
| OPERATING ENVIRONMENT |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°C - 55°C |
| Storage Temperature | -15°C - 60°C |
