24VDC 4000W Pure Sine Wave Power Inverter
| Price: |
Negotiable/Piece |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| 4000W pure sine wave inverter | | | | | |
| Product Features: |
| High transform efficiency, fast start; |
| Pure sine wave output waveform; |
| Softstart function; |
| Strong adaptability and stability ; |
| With automatic over-current and output short circuit protection to avoid damaging the equipment; |
| Temperature-controlled fan, safe & efficient; | | | | |
| Safe and reliable with built-in fuse. | | | | | |
| 1 year warranty (Remarks: Customizable input voltage such as 36v,72v,96v,110v etc; output voltage such as 120v, 130v, 200v etc; Many kinds of sockets are available). |
| Function details: |
| Model | P4000-12A | P4000-24A | P4000-48A | P4000-12B | P4000-24B | P4000-48B |
| Rated Power | 4000W | 4000W | 4000w | 4000W | 4000W | 4000W |
| Peak Power | 8000W(within 5 millisecond) |
| DC Input Voltage | 12V | 24V | 48V | 12V | 24V | 48V |
| AC Output Voltage | 110VAC±10% | 220VAC±5% |
| No-load Current | <2.4A(DC13V) | <1.6A(DC26V) | <1.1A(DC52) | <2.4A(DC13V) | <1.6A(DC26V) | <1.1A(DC52) |
| AC Output Frequency | 50HZ±1%/60HZ±1% |
| AC Output Waveform | Pure sine wave |
| Waveform Distortion | THD<3% |
| Full Load Efficiency | >86%(DC13V) | >88%(DC13V) | >90%(DC13V) | >86%(DC13V) | >88%(DC13V) | >90%(DC13V) |
| DC Input Voltage Range | 10.6V-15.5V | 21.6V-30V | 43.2V-63V | 10.6V-15.5V | 21.6V-30V | 43.2V-63V |
| Low Voltage Alarm | 10.5±0.3V | 21±0.6V | 41.8±1.2V | 10.5±0.3V | 21±0.6V | 41.8±1.2V |
| Low Voltage Protection | 9.5±0.2V | 19±0.3V | 38±0.4V | 9.5±0.2V | 19±0.3V | 38±0.4V |
| Over Voltage Protection | 16±0.5V | 32±1V | 65±2V | 16±0.5V | 32±1V | 65±2V |
| Low Voltage Recovery | 11.8±0.3V | 23.6±0.4V | 47.2±0.8V | 11.8±0.3V | 23.6±0.4V | 47.2±0.8V |
| Over Voltage Recovery | 15.7±0.3V | 31.8±0.4V | 63±1V | 15.7±0.3V | 31.8±0.4V | 63±1V |
| Over-load Protection | 115%-118% |
| Protective Function | Low voltage: LED red light turn on,buzzer warning, automatic recovery |
| Over voltage: LED red light turn on ,automatic recovery |
| Over-load: LED red light on,machine locked, need to be rebooted |
| Over temperature: LED red light turn on,buzzer warning, automatic recovery |
| Short circuit(within 2 seconds): automatic recovery |
| Input reverse connection: Fuse burn-out |
| Work Temperature | -10°C - +50°C |
| Storage Temperature | -30°C - +70°C |
| Humidity | 20%-90%RH without condensation |
| Work Altitude | ≤1200m |
| Size | 446*199*146mm/pc |
| Net Weight | 10.1±0.04kg/pc | 9.84±0.04kg/pc | 8.73±0.01kg/pc | 8.83±0.01kg/pc | 8.78±0.05kg/pc | 9.67±0.05kg/pc |
| Package Size | 575*285*240mm/pc |
| Gross Weight | 12.3±0.05kg/pc | 11.76±0.05kg/pc | 11.42±0.05kg/pc | 12.3±0.05kg/pc | 11.76±0.05kg/pc | 11.42±0.05kg/pc |
Services:
1)The good construction warranty-1 years2)Your can get good reputation from your market and obtain more orders3)Your client satisfied on the right schedule and quality4)Our professional service before and after sale5)The reasonable price6)Any questions from you are welcome and will be replied in 24 hoursFAQ:1. What is inverter?Inverter is an electronic equipment that turn 12v/24v/48v dc into 110v/220v ac.2.How many kinds of output wave form for inverters?Two kinds. Pure sine wave and modified sine wave. Pure sine wave inverter could provide high quality AC and carry various loads, while it requires high tech and high cost. Modified sine wave inverter load poorly not carrying inductive load, but the price is moderate. 3.How do we equip an appropriate inverter for battery?Take a battery with 12V/50AH as an example. Power equal current plus voltage then we know the power of battery is 600W. 12V*50A=600W. So we can choose a 600W power inverter according this theoretical value.
| Prod Model: |
P4000-24-220 |
| Input: |
24VDC |
| Output: |
220VAC |
| Rated Power: |
4000W |
| Peak Power: |
8000W |
| Size: |
446*199*146mm |
| Weight: |
10.1kgs |
| No-Load Current: |
<1.6A(DC26V) |
| Output Frequency: |
50Hz±1%/60Hz±1% |
| Protections: |
Overload&Short-Circuit Protection |
Founded in 2005, SUNKAX Technology Limited is a leading manufacturer and exporter for clean power, such as solar inverter, step up/down voltage transformers, consumer electronics (travel charger adaptors, USB Chargers, output power distribution board, etc. ).
Our products are exported to different countries all over the world, be popular in market for high quality, attractive packing, favorable price, and also excellent service.
With a 19, 000 factory, 8 production lines and over 150 well-trained workers, we turn out 90, 000 units monthly. All our products for export must strictly pass IQC inspections on critical components, 100% online testing, under loading and burn-in testing
SUNKAX has been a pioneer of technology. Back in 2005, we explored the key technology of aluminum transformer production and became the first aluminum transformer supplier
In the automatic voltage regulator field, we developed our own high performance MCU controlled circuit and have obtained several registered patents for our products. We developed air-conditioners stabilizers the best solution to meet your demand.
In inverter/UPS field, We are the 1st to invent toroidal inverters. Which have outstanding advantage of low idle current, low electromagnetic interference, long back-up time and high efficiency. Equipped 32-bit speed CPU control with accurate detection and unique C. R. G. O toroidal transformers, including our solar integrated inverters, all core technology are developed by own R&D team, which makes us one of few factories who holds the key technology.
In guidance of strong R&D team, we are able to produce the exceptional reliable products with the help of skillful working staff, comprehensive quality system and advanced equipments such as newest wave(flow) soldering, and burn-in testing line.
Ongoing research and being creative is what keeping our products at the top of our industry.
Our quality policy:
Everyone participates, continuous improvement, innovation.
Our management idea:
Based on good staff, concentrating on quality and efficiency, keeping on providing customers with excellent service.
Welcome to contact us today for your next OEM/ODM project.
