Ningbo Meya Electronics Co., Ltd. >> 2edgk 3.81mm Has Ear Plug Type 90 Degree 8pin Connector Terminals

2edgk 3.81mm Has Ear Plug Type 90 Degree 8pin Connector Terminals

2edgk 3.81mm Has Ear Plug Type 90 Degree 8pin Connector Terminals
Price: US $ 0.01-1/Piece
Min Order: 100/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: 15EDGK
Environmental Protection: General
Connection Mode: Push-Pull Connection
Contact Termination Form: Screws Fixed
Application: Power,Adapter,Motor
Shape: Square
Type: Pluggable Terminal Block
Character: 8A
Brand: My

Product Description

Description

Rated voltage300V
Rated current8A
Wire range24-14AWG
ScrewM2,Steel,Zinc plated
Insulating MaterialPA66(UL94V-0)
Temperature range-40c/+105c
Terminal blockBrass,Ni plated
Pole No2-24P

Drawing





We are Ningbo Meiyang Electronics Co., Ltd. Located on the South Coast of Hangzhou Bay in Yangtze Delta, where is very close to Shanghai. We are professional in manufacturing terminal block and connector that are widely used in appliance, anti-theft devices, electric power industry automation, instrument and other equipment. We have our own research and development team, and our fine manufacturing system is subdivided into plastic molding, punching molding, hardware manufacturing, injection molding and assembling. We consistently develop in improving quality at same time to reducing cost by lean-production, standardization and increasing production, which make us more competitive and obtain more support and confidence from our customers.

Sincerely we hope our products could be suitable to you and we could provide you with better quality, cheaper price and best service in our cooperation.
