3kw AC Soft Starting Motor (YFM-100G)

Name: 3kw AC Soft Starting Motor (YFM-100G)
Brand: all-electronics-online.com
SKU: 800668395
Availability: InStock
Rating: 4.7 (124 reviews)

Price:	US $ 570-600/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

NoviTrans® Flexible Synchronous Motors
(Saving all equipments and circuits on secondary control loop)

CE / UL certified 3 KW AC Soft Starting Motor
(YFM-100G)

YFM Motor Series' Value Propositions for End-users:

Significant cost savings for end-users (estimated saving range between 30% - 50%)
Significant efficiency improvement of motor system installation, operation and maintenance (at least above 50%)
1 Year Product Warranty

YFM Motor Series' State of the Art Built-in Technical Features:

Self Flexible / Soft Mechanical Power Transmission (no variable frequency drive is needed)
Self Starting Protection (no soft starting devices/circuits are required)
Self Current Limiting Control (minimum current impact pulse)
Self Overload Protection (no overload protection devices/circuits are required)
Self Stalling Protection (no stalling protection devices/circuits are required)
Motor Constant Torque Sustainability (During Stalling)

Secondary control circuit is not required any more since NoviMotors® never burn out. Traditional peripheral equipments on the secondary control loop including soft starting devices/circuits (star-triangle start circuit, variable frequency drive, contactors, motor starter), overload protection devices/circuits (current relay, protector fuse, thermal relay, other electronic protection device) and stalling protection devices/circuits are not needed any more hence the significant cost saving and the ease of motor installation/operation/maintenance.

Note: physical appearance, dimensions, and mounting of YFM Motor Series are exactly the same as normal standard industrial motors. Peripheral motor control equipments/circuits are not integrated into YFM motor series. These special and unique technical features are patented technologies. NoviTrans^®and NoviMotors^®are registered trademarks with patents worldwide (U.S. patent: 14/715,881, 15/112,404; E.U. patent: EP15170787.4, EP14890444.4; China patent: 201510005572.3, 201510005569.1, 201510484613.1, PCT/CN2014/075895; Taiwan patent: 103111604)

Commercial Details:

FOB Price: US$600 / Piece (Patented New Product Launch - Promotional Price Only)
Min. Order: 10 Pieces (for the convenience of transportation)
Production Capacity: 12000 - 25000 PCS per annum
Package: Carton, Plywood Cases, Wooden Cases
Payment Terms: T/T, L/C at sight

Technical Details:

Speed: Constant Speed
Magnetic Nature: Permanent Magnet
Number of Poles: 4
Structure: Rotating Armature Type (Pole Fixed)
Ventilation: Protection Type
Brand: NoviTrans®
Trademark: NoviTrans®
Origin: London, U.K.; Shanghai P. R. China

Application: Industrial / General Purpose
IEC: IE4 Super Premium Efficiency Motor
Number of Stator: Three-Phase
Casing Protection: Protection Type
Certification: CE, UL, ISO9001
Color: Silver
Specification: CE, UL
HS Code:

Product Description: Permanent Magnet AC Synchronous Motor
voltage: 380V / 400V
Frequency: 50Hz / 60Hz

Nominal power Pn: 3 KW
Mounting height of motor axis: 100 mm
Nominal torque:11.46N/M
Nominal current @ 380V rated voltage:6.4A
Pole number: 4
Maximum Torque: 19.1 N/M 120 seconds
Temperature Uprising: <65K
Efficiency Grade: IE4 (GB30253-2013 Grade 1)
Efficiency measurement: 84.3%
Waterproof: IP55
Cooling: IC411 Air cooling
Insulation Grade: F
Mounting: IMB3, IMB5, IMB35

Motor should be used under working conditions of 5ºC to 40ºC and below 90% RH
Motor should be stocked under conditions of -10ºC to 60ºC and below 90% RH

Model	Nominal power	Mounting height of motor	Nominal torque	Nominal current	Maximum Torque	Efficiency measurement	Mounting
550W YFM-80	0.55KW	80mm	2.1N/M	1.8A	3.5N/M	80.80%	IMB3,IMB5,IMB35
750W YFM-80	0.75KW	80mm	3.2N/M	2.0A	4.8N/M	81.50%	IMB3,IMB5,IMB35
YFM-90	1.5KW	90mm	5.7N/M	3.4A	9.6N/M	82.80%	IMB3,IMB5,IMB35
YFM-100	3KW	100mm	11.46N/M	6.4A	19.1N/M	84.30%	IMB3,IMB5,IMB35
YFM-112	4KW	112mm	15.3N/M	8.2A	25.5N/M	86.60%	IMB3,IMB5,IMB35
YFM-132	5.5KW	132mm	21N/M	11.1A	35N/M	87.70%	IMB3,IMB5,IMB35
YFM-160	11KW	160mm	42N/M	21.8A	70N/M	89.80%	IMB3,IMB5,IMB3mode

Prod Model:	YFM-100G
Application:	Industrial
Operating Speed:	Constant Speed
Operation Mode:	Electric Motor
Magnetic Structure:	Permanent Magnet
Structure:	Rotating Armature Type (',Pole Fixed)
Number Of Poles:	Three-Phase
Ventilation:	Protection Type
Brand:	Novitrans

Introduction:

Langham Automatic Co., Ltd. (Langham) was founded in 2014, a high-tech startup focusing on R&D, manufacturing, sales & marketing of advanced mechanical power transmission equipment such as motors, servo motors, servo governors. LED by Dr. Roger LAO and CTO senior engineer Mr. John SHEN, Langham has a very strong R&D capability with over 20 R&D staff and more than 30 patented technologies worldwide in the field of mechanical power transmission.

Dr. LAO earned his PhD degree in Electronic and Electrical Engineering from University College London in the U. K. And his bachelor degree from Shanghai Jiao Tong University, he has over 20 years of research, technical and business experience working as a technical and management consultant for multinational companies such as Siemens, ABB, Yaskawa, GE, Emerson, etc. In the automation and technology sectors. CTO senior engineer Mr. SHEN has nearly 40 years of working experience as the chief engineer leading various teams in the field of automation and mechanical power transmission. Mr. SHEN used to be the CEO and Chief Engineer for a large scale state-owned automation equipment manufacturer in Shanghai for nearly 20 years. He has accomplished numerous high profile projects in his previous tenures including Shanghai Metro power distribution system and Shanghai Expo Stadium stage equipment system.

All Langham products are branded under the registered name NoviTrans® Which originates from two Latin words "novitas transmissio" with the implication of "innovative transmission" technologies. With exclusively patented technologies, Langham successfully developed a whole new breed of integrated intelligent motors with precision production techniques and significantly enhanced the traditional motors with great value added. NoviTrans® Motors / NoviMotors® Have some critical state of the art built-in technical features which revolutionise the traditional application of industrial motors. All equipments/circuits on the secondary control loop are saved (not required any more) with the application of NoviMotors® Which could significantly cut the overall costs for end-users and greatly enhance the efficiency of installation, operation and maintenance of the power/dynamic systems.

Langham has a reliable and robust product quality management system and is able to scale up the production the meet clients' demand. In addition, Langham provides tailor-made technical solutions for clients in various sectors.

Our Products:

Langham has developed three categories of AC permanent magnet synchronous motors:

YFM series (Flexible Motors): Langham's basic motor model in which advanced power transmission technology is applied so that the output mechanical power of the motor can be flexible / soft in its nature. Having the same physical dimensions and the mounting of other general purpose industrial motors, the YFM motor series have the advantage of saving all equipments and circuits on secondary control loop hence the significant overall cost savings and the great efficiency improvement of installation, operation and maintenance of the motor system for end-users.

YVF series (Integrated Servo Motors): Langham's advanced motor model in which servo drive and servo control units are all integrated with the servo motor. YVF motor series feature miniaturization design and compact structure and have the flexible mechanical power transmission nature.

YVM series (Mag-control Servo Motors): Langham's most advanced motor model in which advanced proactive power transmission technology is applied by adjusting the intensity of the magnetic field. Besides flexible power transmission and integrated servo motor in nature, the most important technical feature of YVM motor series is their capability to adjust the output of low-precision decelerator to premium precision in real time hence the significant cost savings for advanced gear decelerators
