3kw Three Phase Asynchronous AC Electric Motor for Fan

Name: 3kw Three Phase Asynchronous AC Electric Motor for Fan
Brand: all-electronics-online.com
SKU: 822197555
Availability: InStock
Rating: 4.6 (122 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

Product Description
NEMA Stainless Steel Motor

TECHNICAL CHARACTERISTICS

Rated outputs and frame sizes in accordance with NEMA standards
Duty type S1(continuous duty) with sufficient thermal margin to withstand short overload
Degree of protection: IP43
Insulation class F, temperature rise class B
Maximum ambient 40° C
Altitude ≤ 1000m a. S. L
Service factor 1.15
Manual or automatic overload protection when required

CONSTRUCTION MATERIALS
Aurora Aqua-tech series NEMA Stainless Steel Motor
1All 304 Series Stainless Steel 56C Through 286TC Frames
2. Class "F" Insulation With 1.15 Service Factor
3. Laser Cut nameplate
4. Stainless Steel Slinger with built in teflon seal
5. Frames "C" Face Footed &"C" Face Footless

Frame-steel, stainless steel slinger with built in teflon seal, TEFC, TENV, JM and JP Frames all available, all triple lip seals
End shields-pressure cast aluminium
Fan cowl- plastic
Fan-plastic
Shaft- medium carbon steel(stainless available on request)
Terminal box- steel
Capacitor box-steel

APPLICATION

Pumps, fans and blowers, farm equipment, conveyors. Machine tools. Gear reducers and other applications.

American motor(stainless steel motor) are always used for pharmaceutical, poultry, beef, pork, dairy, bakery, snack food, bottling chemical applications and other environment that require extreme cland frequent washdowns.
Noise Levels: DBA noise is the lowest in industry.
NEMA Stainless Steel Motor, Exceeds NEMA EPACT Efficiency standards

NEMA Stainless steel motors detailed specification
NO.	Power	Frame
1	1/3HP-2HP TEFC, TENV 3-PH	56C Foot(Footless)
2	3HP-5HP TEFC, TENV 3-PH	180TC, 184TC Foot(Footless)
3	7.5HP-20HP TEFC 3HP	213-256TC Foot(Footless)
4	1/3HP-5HP JM/JP TEFC 3-PH	56C-184TC Foot(Footless)
5	7.5HP-20HP JM/JP TEFC 3-PH	213-256TC Foot(Footless)

Prod Model:	0.5HP-10HP
Number Of Stator:	Single-Phase
Function:	Control
Certification:	UL
Brand:	Xinzheng

Jinhua Xin Zheng Motor Co., Ltd. Focuses on the manufacture and research of stainless steel motor for more than twenty years. It is a leading brand of motor industry which integrates R & D, production, sales and service. The company has strong technical strength, advanced production equipment, sophisticated testing equipment, strict process technology, perfect inspection system.

The company has 20000 square meters of production base, has a complete motor processing, assembly lines and advanced inspection and testing system. According to customer demand design products, meet the needs of users, provide good, beautiful products. The company's main motor product shell uses food grade 304 stainless steel, not rust, high temperature resistance, corrosion resistance, washable, suitable for medical, food and other health fields requiring higher industry. The listed products are certified by CE, UL, CCC, ISO9000, as well as SGS factory certification, and obtained the patent of design.

At present, the company's manufacturing R & D capacity has reached the international advanced, domestic leading level. With reliable product quality, high quality service, has been to many countries and regions in Europe and North America, user recognition, and with well-known German SEW, American Boston Gear enterprises to establish a good relationship of cooperation.

The company is willing to make high quality products, excellent prices, efficient service to make friends from all walks of life in the world, welcome to the factory on-site inspection, common development.
