400A MCCB 3p Moulded Case Circuit Breaker (AM3T)

Name: 400A MCCB 3p Moulded Case Circuit Breaker (AM3T)
Brand: all-electronics-online.com
SKU: 607130924
Availability: InStock
Rating: 4.5 (119 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Application

AM3T moulded case circuit breaker is suitable for circuit AC 50Hz/60Hz, rated voltage up to AC 660V, rated operating current up to 250A. It features normal structure, reliable performance, high breaking capacity, used for power distribution and protecting the circuit and electrical equipment against overload and short circuit. It complies with standard of IEC60947-2.

Type		AM3T-160	AM3T-250
Poles number		3	3
Rated current In(A)		16~160	100~250
Rated operating voltage Ue(V) (50/60Hz)		690	690
Rated insulation voltage Ui(V)		800	800
Rated impulse withstand voltage Uimp(KV)		8	8
Utilisation category		A	A
Rated limited short-circuit breaking capacity Icu(KA)	220/230V	25	50
	380/415V	16	36
	400V	10	25
	500V	8	20
	690V	3	5
	500V-3poles in series	16	36
Rated short-circuit service breaking capacity Ics(%Icu)		100	75

Prod Model:	AM3T
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current In(a):	16~160, 100~250
Rated Operating Voltage Ue(V) (50/60Hz):	690
Rated Insulation Voltage Ui(V):	800
Rated Impulse Withstand Voltage Uimp(Kv):	8
Arc-extinguishing Medium:	Air
Breaking Capacity:	Low Voltage Circuit Breakers
Poles Number:	3
Operation:	Manual Type
Installation:	Insert
Speed:	High-Speed Circuit Breaker
Structure:	Moulded Case Circuit Breaker
