48pin Screw Power Terminal Heavy Duty Connector Similar Ilme

Name: 48pin Screw Power Terminal Heavy Duty Connector Similar Ilme
Brand: all-electronics-online.com
SKU: 832720935
Availability: InStock
Rating: 4.8 (23 reviews)

Price:	US $ 7-14/Set
Min Order:	10/Set
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

SMICO heavy duty connector are extensively used in quipment that requires electrical and signal connections,such as mold,machinery,construction machinery, textile machinery,transportation technology,electric energy,electric locomotives and so on various need electrical and petrochemical electrical equipment.

Insert:

Number of Contacts	48
Electrical Data Acc.to	EN61984
Raled Current	16A
Raled Voltage	500V
Raled Impulse Voltage	6KV
Pollution Degree	3
Flammability Acc.to (UL94)	VO
Insulation Resistance	≥10 ¹⁰Ω
Material	Polycarbonate
Limiting Temperature	-40ºC±125ºC
Mechanical Working Life
Mating Cycles	≥500

Contacts:

Material	Copper Alloy
Surface	Hard-silver Plated
Contact Resistance	≤0.5mΩ
Crimp Teminal Wire Gauge	1.0-2.5mm²
Max.Insulation Diameter	11mm
Stripping Length	7-9mm

Prod Model:	SO-HE-048
Working Current:	16A
Working Voltage:	500V
Pollution Degree:	3
Rated Impulse Voltage:	6kv
Flammability:	Vo
Limiting Temperature:	-40oc~+125oc
Mechanical Working Life:	Above 500
Working Voltage Acc To UL/CSA:	600V

Zhejiang Smico Electric Power Equipment Co., Ltd. Located in Liushi Town, Yueqing City, the China Electrical City. Have conveniently traffic 25km respectively from Wenzhou airport and railway station, and 5km from 104 national road freeway.

SMICO CONNECTOR is a leading professional manufacturer specialized in heavy duty connector, electric power fittings, switches and so on. SMICO connectors are suited for the hardest requirements in industrial environmenont. SMICO connector has been widely used in Automatic, machine made, power and equipment industries. SMICO connector is in conformance with the standard DIN 5510-2 and EN 61984.

As we strive to hold on our promise of "Human Oriented, Technology Advanced", we make hard effort to increase our global market presence. We strictly produce the goods accordance with the ISO9001, and most of for our products have the CE and CB certificate.

We will improve ourselves all the time and sincerely invite you who interested in our products to develop the business together. We are always your electrical friends.
