5.5kw Solar Photovoltaic Compressed Water Pump DC-to-AC Inverter of 380V Triple (3) Phase Output

Name: 5.5kw Solar Photovoltaic Compressed Water Pump DC-to-AC Inverter of 380V Triple (3) Phase Output
Brand: all-electronics-online.com
SKU: 832786735
Availability: InStock
Rating: 4.6 (41 reviews)

Price:	US $ 124-160/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Technical Features
♦Flexibility◊
◊Compatible with IEC standard three-phase asynchronous induction motors
◊Compatible with popular PV arrays
◊Grid supply option

♦Reliability
◊10-year market proven experience of leading motor and pump drive technology
◊Soft start feature to prevent water hammer and increase system life
◊Built-in overvoltage, overload, overheat and dry-run protection

♦Cost Effectiveness
◊Plug-and-play system design
◊Embedded motor protection and pump functions
◊Battery-free for most applications
◊Effortless maintenence

♦Smartness
◊Self-adaptive maximum power point tracking technology up to 99% efficiency
◊Automatic regulation of pump flow
◊Self-adaption to the motor used in the installation

♦Remote Monitoring
◊Standard RS485 interface equipped for each solar pump inverter
◊Optional GPRS/WIFI/Ethernet RJ45 modules for remote access
◊Spots value of solar pump parameters monitoring available from anywhere
◊History of solar pump parameters and events lookup support
◊Android/iOS monitoring APP support

Prod Model:	SK650-5D5G-4
Rated Power:	5.5kw
Output Current:	13A
Output Frequency:	0Hz~60Hz
Output Voltage:	380V AC 3 Phase
Input Voltage:	350-750V DC or 380V AC 3 Phase
Package Weight:	4kgs
Product Size:	246150176mm
Application:	High Frequency Converter Transducer
Output Type:	Triple
Principle Of Work:	Vector Control Transducer
Switch Mode:	High Carrier Frequency PWM Control
Main Circuit Type:	Voltage
Link Of Transformation:	DC-AC Variable Frequency Drive & AC-DC-AC Also
Function:	Pump Special
Brand:	Sako

SK600 series are high performance vector inverters. Our products are based on control system of high performance 32 bit digital signal processor (DSP), of which the control software integrates advanced current vector control technology and flux vector control technology. It realizes the speed control of AC motors, rated torque output by low frequency and stable operation.

SK600 series inverters are equipped with a variety of built-in control mode, protection and alarm function, which makes the operation data visual and has excellent control performance. Inverters can be used for driving a three-phase asynchronous motor and provide excellent driving function, meeting various transmission applications.

SK600 series inverters are with high integration, reasonable structure, complete protection function and high reliability; In the aspect of the hardware configuration, we use the leading domestic and foreign brands, to ensure the reliability of the product; In the aspect of software, our products fully meet customer maneuverability, meet more wide application demand and achieve the domestic leading level of similar products.
