5000W Pure Sine Wave DC to AC Solar Power Inverter
| Price: |
US $ 345-380/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
Products Features
1. Input & output fully insolated
2. High Surge: High surge current capability starts difficult loads such as TVs, camps, motors and other inductive loads
3. Soft start: Smooth start-up of the appliances.
4. Pure sine wave output waveform: Clean power for sensitive loads.
5. AC output identical to, and in some cases better than the power supplied by your utility
6. Cooling fan in the inverter is thermally activated and comes on when the inverters becomes warm, and turns off automatically after the inverter has cooled.
7. Low total harmonic distortion: Below 3%
8. Two LED indicators on the front panel shows the working and failure state.Protection Function1. Low voltage alarm & Shutdown
2. Over-voltage protection
3. Overload protection
4. Over-temperature protection
5. Short circuit protection
6. Soft start
7. Auto. Reset after being in protected
8. Grounding protection
Technical Specifications | Model | CZ-5000S |
| Input | DC voltage | 12V | 24V | 48V | 110V |
| Voltage range | 10-16VDC | 20-33VDC | 40-63VDC | 90-130VDC |
| No load current draw | 3A | 1.5A | 0.8A | 0.4A |
| Efficiency | > 90% |
| DC connection | Cables With Clips or Car Adaptor |
| Output | AC voltage | 100/110/120VAC or 220/230/240 VAC |
| Continuous power | 5000W |
| Surge power | 10000W |
| Waveform | Pure sine wave |
| Frequency | 50Hz or 60Hz |
| AC regulation | 3% |
| Protection | Low voltage alarm | 10.5DC±0.5V | 21DC±1V | 42VDC±1V | 96VDC±3V |
| Low voltage shut down | 10DC±0.5V | 20DC±1V | 40VDC±1V | 90VDC±3V |
| Short circuit | Shut off output automatically |
| Over load | Shut off output |
| Over voltage shut down | 16±0.5V | 33±1V | 63±1V | 130±3V |
| Over thermal | Shut off output automatically |
| Environment | Working temperature | Between -10ºC and +50ºC |
| Working humidity | 20%~90%RH |
| Storage temperature | Between -30ºC and +70ºC |
| Package | Machine size(mm) | 520*217*153 |
| Packing size(mm) | 605*300*230 |
| Net weight(kg) | 13.1 |
| Gross weight(kg) | 15.5 |
| Packing mode | Carton packaging |
| Other | Start | Soft start |
| Cooling ways | Intelligent cooling fan |
Custom-made available:
Except for the regular DC input voltages: 12V, 24V, 48V, we also could provide customized DC input voltages: DC 36V,DC 60V,DC 72V,DC 84V,DC 96V,DC 110V,DC 120V,DC 220V. |
Inverter Details
Workshop
Exhibition
Certification
Packing Details
1pcs/CTN, unit box size 68*33*28cm,N.W13.1kg, G.W15.5kgDelivery detailsAbout bulk order, it's up to your quantity, almost within 30days.
About sample, it's within 5 days.Payment and Shipping1. We accept T/T, Paypal, Western Union, Money Gram;
2. For sample, it's better via Paypal or Western Union; For quantity order, we can go for T/T;
3. For small order, we usually transport by express like FedEx, DHL, TNT, EMS.
For big order, we can ship by air or by sea.
| Prod Model: |
CZ-5000S |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
Solar Power Inverter |
| Input Voltage: |
12V/24V/48V/110V |
| Output Voltage: |
100-120V/220-240V |
| Wave: |
Pure Sine Wave |
| USB Port: |
5V |
| OEM Service: |
Available |
| Color: |
Blue/Silver |
| Warranty: |
2 Years |
| Frequency: |
High Frequency |
| Category: |
off Grid Inverter |
Yueqing Yongmao Power Co., Ltd. is an innovative scientific and technological enterprise, specialized in integrating the R&D, manufacturing, selling and serving for power inverter ( solar, wind and home system), we can provide the wide power from 150W to 6000W, the products of our company are widely used in various fields as new energy generation, electricity supply, telecommunication, aerospace, national defense, transportation and scientific research institutions etc.
With rich experience in technique researching, designing, manufacturing process, quality control, before-after sale service for power supply products, the company becomes an important base for power supply products at home and abroad, enjoying a high reputation and good popularity.
Good quality, best price and better technical support and service, make Yueqing Yongmao Power Co., Ltd. As your most valuable cooperator in China.
Our enterprise purpose: Trusted partner of customers, home for growth of employees, excellent member of industry.
Enterprise mission: High-quality suppliers in the electronics industry.
Enterprise core values: Forge ahead, solidarity and farsighted, l earning continuously.
Management philosophy: To inspire individual potential, Progress together with staff; Improve product quality and achieve win-win with customers; Unmoved in development goals, go on with the world.
Create value for customers, help growth of employees, hold on social responsibility. Yongmao advocate for employees to create a harmonious and pleasant working and living environment, fully stimulate the creativity and sense of being masters. Yongmao actively give financial aid to students, make donations to earthquake disaster area, and involved in all kinds of charitable activities and public utilities, such as poverty alleviation. We actively contribute to the community, truly live up to our belief "change oneself with its growth and to return society with achievement"
