60W 90mm High Voltage Brushless DC Motor

Name: 60W 90mm High Voltage Brushless DC Motor
Brand: all-electronics-online.com
SKU: 743459115
Availability: InStock
Rating: 4.8 (51 reviews)

Price:	US $ 24.3-25.2/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Introduction
Brushless dc motor (bldc) is made up of motor and driver, which is a kind of typical product of mechanical and electrical and electrical integration. It is high regarded by market as its small volume, low noise, high efficiency, wide range of speed control and steady working state with less inaccuracy.

Specifications
1. Dimensions of device: Dia62mm
2. Rated Power: 60W / 70W
3. Voltage: 24V
4. CCC, CE, UL, CU
5. Can be customized

Greensky's advantage
On the site you can find a range of renewable products including ac/dc motor, ac induction motor, reversible motor, blake motor, speed motor, ac angel motor, gear motor, planetary gear box, worm gear box and their relevant components.

If you have any other questions, please feel free to contact us.

Model	Voltage V	Rated Power W	No-load Parameters		Load Parameters			Motor Life H	Motor Weight kg
Model	Voltage V	Rated Power W	Speed RPM	Current A	Speed RPM	Torque N.m	Current A	Motor Life H	Motor Weight kg
4BLD60-24	24	60	3300	MAX0.50	3000	0.19	3.2	>5000	1.2
4BLD60-36	36	60	3200	MAX0.35	3000	0.19	2.1	>5000	1.2
4BLD60-48	48	60	3200	MAX0.25	3000	0.19	1.6	>5000	1.2

Prod Model:	4BLD60-36
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
All Technical Data:	Can Be Customized
Application:	Power Tools
Operating Speed:	High Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brush
Certification:	UL\CE\RoHS
Brand:	GS
