69KV 6KN Polymer Post Insulator

Specification:
1. Rated voltage: 69KV
2. MDCL: 5.9KN
3.Structure height H: 864±15mm
4. Insulating distance H.: 660mm
5. Creepage distance: 1900mm
6. Dry power frequency withstand voltage: 251KV
7. Wet power frequency withstand voltage: 209KV
Standard applied: IEC61952

======================================================================================
Suspension Silicon Insulator / Polymer Insulator / Composite Insulator

Rated Voltage 10---500kV, rated failing load 70--160kN; Confrm with international standard; OEM or ODM are welcome;

Usage: The product are suitable for the innovation of urban electrical network where it can increase the voltage and transport the electricity effectively by using the narrow street. And it can reduce the necessary height of the pole/tower. Due to it's high stength of bending, it will comepletely avoid the crack case that happened on porcelain crossarm. Moreover, it can be well pollution resistan.

We also special supply according to your specification, pls send us details.

Figure No.	Model	Rated Voltage	Specified Mechanical Load	Coupling Size	Section Length	Insulating length	Shed diameters	Shed Spacing	Grading Ring Diameter	Minimum Creepage	Full-Wave Impulse Withstand Voltage (Peak)	Wet Switching Impulse Withstand (Peak)	1 Min Wet Power Frequency Withstand Voltage	Weight (for Reference)
		kV	kN		H mm	h mm	d1/d1/d2 mm	B mm	D1/D2/D3 mm	L mm	≥ kV	≥ kV	≥ kV	kg
1	FXBW-±1000/(420/400)	±1000	420/400	28	11000±50	10000	246/158/98	158	1600/600/400	40000	±4500	±2400	±1125	136
2	FXBZ-±800/(240/ 210/180/160)	±800	240/210/ 180/160	20	8700±50	8000	246/158/98	158	1120/560/232	31100	+3600	+1950	+900	115
3	FXBW-750/(120/100)	750	120/100	16	7150±50	6500	174/88	79	440/450/500	23800	2700	1800	1120	52
4	FXBZ-±660/(240/ 210/180/160)	±660	240/210/ 180/160	20	7800±50	7100	174/88	79	600	25800	+3200	+1800	+780	58
5	FXBZ-±500/(240/ 210/180/160)	±500	240/210/ 180/160	20	5440±50	4900	174/88	79	400	17600	+2550	+1550	+600	36
6	FXBW-400/(120/100)	400	120/100	16	3910±50	3300	171/85	79	370	12800	2250	1240	740	27
7	FXBW-330/(120/100 /70)	330	120/100/70	16	2990±40	2600	162/86	95	305/350	9400	1425	950	570	19
8	FXBW-220(230)/(120/100/70)	220/230	120/100/70	16	2240±30	1900	162/86	95	305/250	6800	1000		395	12
9	FXBW-110(115)/(120/ 100/70)	110/115	120/100/70	16	1240±15	1000	162/86	95	250	3300	550		230	5.3
10	FXBW-69(66/63)/ (120/100/70)	69/66/63	120/100/70	16	940±15	740	162/86	95		2200	410		185	3.7
11	FXBW-15(12/11/10)/ (80/70/40)	15/12/11/10	(80/70/40)	16	340±3	163	150/115/80	50		400	95	60	400	1.4

Prod Model:	CE-FC-69/6
Creepage Distance:	1900kv
Insulation Distance:	660
Structure Height:	864
Mdcl:	5.9kn
Application:	High-voltage
Material:	Composite Polymer
Type:	A Type Insulator
Structure:	Horizontal Mounting Post Line
Size Of Bearing Capacity:	69kn
Color:	Grey
Brand:	Cowinelec, OEM,ODM
