IntroductionZW28-12 series AC high voltage vacuum circuit breaker can be used in the AC 50Hz, rated voltage 12kV three-phase electric net. Mainly are installed in the handcart type and fixed type switchgears.
For the protection & control of the electric equipments in mining ,iindustrial companies, power plants and substations.
Suitable for distribution systems and frequent operation places.
Surrounding1. Ambient temperature: -10ºC~+40ºC 2. Altitude below 1000m
3. Wind pressure ≤700Pa(Wind Speed is 34m/s)
4. Relative diary average temperature ≤95%, monthly average≤90%
5. Shock degree ≤8 class.
Specification| Rated Voltage | 12KV |
| Rated short-circuit breaking current | 20KA, 25KA, 31.5KA, 40KA |
| Power frequency withstand voltage(1 min) | 42KV |
| Lightning impulse withstand voltage | 75KV |
| Rated short-circuit CO current | 50KA, 63KA, 80KA, 100KA |
| Rated moving steady current | 50KA, 63KA, 80KA, 100KA |
| Rated thermal steady current | 20KA, 25KA, 31.5KA, 40KA |
| Rated thermal steady time | 4s |
| Rated short-circuit breaking current breaking times | 30 times |
| All breakig time | ≤100ms |
| Mechanial life | 10000 times |
| Rated operating order | O-0.3s-CO-180s-CO(electric mechanism) |
Mechanical parameter
| Open contact clearance | 11±1mm |
| Contacts over travel | 4±1mm |
| Three phases opening synchronizaton | ≤2ms |
| Contact making spring time | ≤2ms |
| Oil buffer travel | 10mm |
| Phase core distance | 210/230/250/275mm |
| Average breaking speed(before contact oil buffer) | 1.1±0.2ms |
| Average making speed | 0.6±0.2ms |
| Breaking time | Max/rated operation voltage:≤0.05s; Min operation voltage:≤0.06s |
| Making time | ≤0.1s |
| Moving contacts accumulative admitted wearing thickness | 3mm |
Outline and mounting dimension
Packing and shipping-- Ordinary paper carton for products.
-- Shipping mark according to customer's request.
-- Bulk production will be deliveried by sea and air.
Our Service
-- We have our own factory, professional manufacturer
-- We can send you samples within two weeks.
-- We do OEM & ODM services .
-- We control quality strictly, quality problem: 100% compensation or change
Welcome to visit our factory. Welcome customer or your agent to inspect before order and before lading.
