BNC Female Connector to SMA Male Connector

Name: BNC Female Connector to SMA Male Connector
Brand: all-electronics-online.com
SKU: 834008335
Availability: InStock
Rating: 4.4 (25 reviews)

Price:	US $ 0.01-1/Piece
Min Order:	5000/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Basic Info

Model NO.: XT-B 004
Type: BNC Connector
Certification: ISO9001, ISO
Fastening Type: Snap-On
Insulating Materials: Polystyrene
Materials: Brass
Item Name: Waterproof BNC Connector Price
Insulation Resistanc: More Than The 5000mohm
Resistanc: Inner Conductor ≤2.0mohm
Frequency Response: DC to 8 MHz
Center Pin: Gold-Plated Pure Copper
Transport Package: 100PCS/Polybag, 5000PCS/CTN
Origin: Yangzhou City, Jiangsu Province, China

Application: Audio & Video
Plating: Nickel
Gender: Female
Mounting Type: Through Hole
Contact Finish: Tin
Standard: BNC
Impedance: 50ohm / 75ohm
Frequency Range: 0~2GHz
Medium Pressure: 1500V
Applicable Standard: IEC 60169-24
Trademark: Xuntong
Specification: CE\RoHS\SGS\ISO9001\IAF\CNAS
HS Code: 8536909000

Product Description
BNC female jack nut bulkhead right angle PCB mount RF connector
PRODUCT SPECIFICATIO

Characteristic Impedance	75ohm
Frequency Range	DC-4GHz
VSWR	≤1.30@DC-1000MHz
Insertion Losss	≤0.2dB
Working Vlotage	500V RMS,50Hz,at sea level
Dielectric Withstanding Voltage	≥1500V RMS,50Hz,at sea level
Dielectric Resistance	≥5000MΩ
Contact Resistance	Center Contact ≤1.5mΩ	Outer Contact ≤1.0 mΩ
Durability	Mating cycles ≥500
Parts Name	Material	Plating
Body	Brass	Ni
Insulator	PTFE	-
Inner Conductor	Phosphor Bronze	Au
Coupling Nut	Brass	Ni
Gasket	Silicone Rubber	-
Ferrule	Annealed Copper	Ni
Operating Temperature	_45 °C~-85 °C
Weatherproof Rate	IP67
RoHs (2002/95/EC)	Compliant by exemption
Suitable Cable Family	RG59 Cable

Type:	Double Coaxial Connector
Coupling Mechanism:	Clamping Type

Jiangsu Telaisi Electronical Equipment Co., Ltd was founded in 1995 and located in Jiangsu Province. Our factory is a professional manufacturer of R&D, producing RF connectors and cable assemblies, processing various components.

The factory independently developed products commonly used specifications of SMA\SMB\SMC\BNC\L9\MCX\MMCX\TNC\FME\RCA connectors, RG59\RG6\RG11 series connector heads and all kinds of waterproof connector. The factory has a professional R&D team, combined with years of R&D experience, can address the specific customer needs and can provide customers with professional technical support.

Our factory is not only committed to continue to build and improve the product platform but also to establish Quality Management System and Environmental Management System at the same time, and provide solid backing for the factory's sustainable and stable development. The factory passed ISO9001 quality management system certification and ISO10041 environment system certification in 2008. Our products obtained from Taiwan\Japan\Vietnam\Thailand\Europe&America and the domestic customer's recognition and praise.

Since the plant, we have taken the market as the core, taken the product as the guideline, taken technology as the foundation, taken the quality as the lifeblood. For the domestic and foreign markets, we implement brand strategy and take brand development.

Our factory has a broad market prospects. Products are widely used in CATV communication digital network\aerospace industry\satellite transmission\photoelectric transmission and other types of industrial, civil and military fields.

We sincerely welcome domestic and foreign customers to come to discuss cooperation and common development.
