C331 5.8GHz 200mw Wireless Mini Fpv System Flysight Transmitter and Receiver Tx5802+RC306 32CH for Dji Phantom

Prod Model:	TX5802+RC306
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	Rx Size: 55*40*15mm ;Tx Size:57*27.2*12mm
Application:	Image Transmission, Video Transmission
Modulation:	Channel Chaning Button
Receiver Chip:	Tx Rx
Oscillator Circuit:	N

Product Description

C331 5.8ghz 200mw wireless mini fpv system flysight transmitter and receiver TX5802+RC306 32ch for dji phantom Features of 5.8G 200mW AV wireless transmitter: A.5.8G 32ch transmitter B.With channel button to change channels easily C.Channel memory function for power-off D.Very light and ultra mini size The mini but powerful 5.8G 200mw transmitter would make your fly to 1-2 km away with only the stock antenna, advanced build-in regulator offers this transmitter very wide power input range. Specifications of transmitter: Transmitter frequency:5645-5945MHz;32CH Transmitting Power:200mW/23dBm Transmitting distance:>2000m(open area) Frequency control:Built-in frequency and phase lock loop ANT connector:SMA(inside the needle) AV input:Analog AV signal input Power supply:6-16 volts Current supply:130mA Size:57*27.2*12mm Net weight:16g(no cable and antenna) Note:Antennas must be attached before powering on. Receiver RC306 Receiving frequency:5665-5945MHz;32CH Receiving sensitivity:-90dBm Frequency control:Built-in frequency and phase lock loop Double lines AV output:Analog AV signal output Antenna connector:SMA(Inside the needle) Power supply voltage:6-16V Supply current:60mA Dimension:55*40*15mm(aluminium alloy extrusion profiles) Note:The av cable uses 3.5mm plug on the receiver RC306 Our service: 1.Your inquiry related to our products or prices will be replied in 24hrs. 2.Well-trained and experienced staffs to answer all your enquires in fluent English 3.OEM&ODM, any your customized lightings we can help you to design and put into product. 4.Distributor ship are offered for your unique design and some our current models 5.Protection of your sales area, ideas of design and all your private information FAQ: 1.FOB Price: At present, we only offer EXW price to all our customers for small orders, but for a large quantity order shipped by container, we will offer you FOB Shenzhen price. 2.Payment term: At present, we only accept T/T and West Union payment method. 3.Minimum Order Quantity(MOQ): No matter what quantity you want, we will try our best to offer it to you.Usually, our M.O.Q is 50 PCS/kits for each item. 4.Price list: Please visit our website and choose your interested products.Price list of the items you selected will be sent to you after receiving your return email.Our price will depend on your order quantity.We are a manufacturer of our products, so we promise to offer you the best price. 5.Delivery time and OEM Order If the products are NOT made based on your Trade Mark, we can send the goods to you in one week after we receive your payment. There is no problem for us to make the products based on your brand, but the price should include the cost of gift box and you should provide us your design.The delivery would be around 35 days due to printing the gift boxes from the very beginning, but it would only need around 20 days for the repeated order. 6.Shipping: We normally suggest our customers to choose DHL Express if the order is not so large.For a large order, we recommend air freight to save your shipping cost.The shipping cost will depend on the total weight of your order. 7.Warranty: We offer 1 year warranty of free repair or replace for all our products.If the goods have quality problem, we will replace within 3 months.In this case, we will have the faulty goods returned at first, and then we send the new ones to you with your next order. If you have any other questions please feel free to contact with me in any time.
