C332 Tx58025+RC306 6-28V 200m Remote Distance AV Transmitter+Receiver for RC Hobby Plane

C332 TX58025+RC306 6-28V 200M Remote Distance AV Transmitter+Receiver for rc hobby plane

Features:

1. With channel button to change channels easily
2. Channel memory function for power-off
3. Four groups frequencies can be offered

Specifications of transmitter:

Transmitter frequency: 5645-5945MHz; 21CH
Transmitting Power: 5mW/14dBm
Transmitting distance: >200m(open area)
Frequency control: Built-in frequency and phase lock loop
AV input: Analog AV signal input
ANT connector: SMA and RPSMA optional
Power supply: 6-16volts
Current supply: 70mA
Size: 57*27.2*13mm
Net weight: 17g(no cable and antenna)

Note: Antennas must be attached before powering on.

Receiver RC306:
Receiving frequency: 5665-5945MHz; 32CH
Receiving sensitivity: -90dBm
Frequency control: Built-in frequency and phase lock loop
Double lines AV output: Analog AV signal output
Antenna connector: SMA(Inside the needle)
Power supply voltage: 6-16V
Supply current: 60mA
Dimension: 55*40*15mm(aluminium alloy extrusion profiles)

Note: The AV cable uses 3.5mm plug on the receiver RC306
