C45 Dz47-63 Mini Circuit Breaker

Name: C45 Dz47-63 Mini Circuit Breaker
Brand: all-electronics-online.com
SKU: 615750034
Availability: InStock
Rating: 4.3 (70 reviews)

Price:	US $ 0.766/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

C45 Mini Circuit Breaker
Application:
CEB45 series circuit breaker is used in lighting distribution system or motor distribution system for protecting overload and short-circuit in the system.

Characteristic:
The product is novel in structure, light in weight, reliable and excellent in performance. It has high breaking capacity, can trip quickly and Its installation uses with guide, Its case and items are adopted with high fire-resistant and shockproof plastics.

Standard:
The product, with long life, is mainly used in AC 50Hz/60Hz single-pole 240V or two, three, four-pole 415V circuit for overload and short-circuit protection as well as for unfrequent on-and -off switching electric equipment and lighting circuit in normal case. The product complies with GB10963, IEC60898, BS387

Rated Voltage(V)	230(240)/400(415)
Rated Current(A)In	32,40,63,80,100
Frequency(Hz)	50/60
Short-circuit Bears To Suffer Capacity	Connected to 100A, Fuse to 25KA
Making or Breaking Capacity	1.25In;1.1Ue
Usage Category	AC22
Connection Wire Cut	Max.50mm*2
Protection Grade	IP40(Install the term)
Insulate	Appearance of clear and definite switch Position according to DIN VDE0106

Prod Model:	CEB45-1P
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current:	1-63A
Rated Voltage:	1p 230/415V, 2/3/4p 400V
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	MCB
Certification:	ISO9001,ISO14001
Poles Number:	1p,2p,3p,4p

Founded in 1999, CEA Group International Co., Ltd.Is being acknowledged as one of the most respected nationwide manufacturers and exporters of low voltage electrical apparatus in P.R of China.

The Group, comprising 5 factories, owns a production area of 50, 000m2 and employs more than 1, 000 staff.During the past 13 years, we invested abundant resources in both research and development and employee training programs.The company was ranked in the front of 100 tops of wenzhou private enterprises." CEA" is named as a famous trademark in domestic and overseas markets.Our company has took the lead in applying IS09001 Quality Management System and ISO14001 Environmenttal Management System.Many products are certified under international certificate, such as CB, CE, BS, VDE, UL, SONCAP, CCC.

Currently, we have manufactured and exported more than 160 varieties of products, with over 2000 types of low voltage electrical apparatus including all kinds of LED lighting, Circuit Breakers, Contactors, Relays, Starters, Switches, , Wire & Cable and Electrical Accessories etc.As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching South East Asia, Middle East, South America, Africa, Europe.

We are fully aware of the fact that only "Versatile Staff, Distinctive Quality and Advanced Technology"enable us to survive and succeed in today's intensively competitive market.Hence, we will be with overall technology support, good service to meet the requirements of world.

Enquiries from both domestic and overseas customers are cordially welcomed.Just Tell Us Your Requirements and Let Us Do The Rest For You!
