Cap and Pin Type Suspension Porcelain Composite Insulator

Name: Cap and Pin Type Suspension Porcelain Composite Insulator
Brand: all-electronics-online.com
SKU: 784971605
Availability: InStock
Rating: 4.9 (141 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	FXWP-70 and so on
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lead Time:	20days
ODM And OEM:	Accept
Brand Name:	L&R or as Per Clients' Requirements
Size:	Any Size Can Be Ordered
Structure:	Suspension Insulator
Material:	Porcelain and Composite Polymer
Brand:	L&R or as Customized

Product Description

Basic info.
Origin: Yueqing, Wenzhou, Zhejiang, China
Brand name: As per customers' requirements
Delivery: By sea, by air or by express
Packing: Clean poly bags plus cartons plus pallets or as customized

TECHNICAL SPECIFICATION

Model No.	Main Parameters			Connection Type Mark	Electromechanical Failure Load (kN)	Lightning Full Wave Impulse Withstand Voltage (peak) (KV≥)	Power Frequency Voltage (kv)
Model No.	Nominal Structure Height (H)	Nominal Shed Diameter (D)	Maximum Nominal (L)	Connection Type Mark	Electromechanical Failure Load (kN)	Lightning Full Wave Impulse Withstand Voltage (peak) (KV≥)	one miniute wet withstand voltage	sparkover
FXWP-70	146	280	400±16	16	70	120	45	120
FXWP-100	146	320	440±16	16	100	120	45	120
FXWP-120	155	320	440±16	16	120	120	45	120
FXWP-160	155	320	440±16	20	160	130	50	120
FXWP-210	170	320	440±16	20	210	130	50	120

Zhejiang Lawrence Electric Co., Ltd (referred as L&R) is located in Zhejiang China. It is composed by some branch companies, we also invested some domestic and foreign EPC projects.

L&R has possessed one of the major suppliers in the power and electrical fields for electrical

Projects in the world. Almost all products manufactured by the L&R members have been certified

By KEMA, CE, SGS and CNAS approved Lab.

L&R have been supplying Zinc Oxide Varistors, Surge Arresters, insulators, Fuse Cutouts, Air

Break switch, Load break switch, Vacuum Circuit Breaker, Isolators, Transformers, Switchgear,

Earth rods, Stay Rods, Pole Make Off, Guy grip, stay wire, Crossarm, clamp, bolts, Line hardware

And so on. Our member companies are required to have a long term proven track record of meeting contract

Obligations, superior quality, current technology and state-of-the-art manufacturing facilities.

Over a period of 10 years, our business has extended to South America, Middle East, Southeast

Asia, Africa, and other regions, and we had our sale agent and 4S maintenance company in some countries. To achieve the strategic objective of development, we are seeking for partners

For our sale agent and maintenance company in all the worldwide.
