Cat5e CAT6 Networking Cable for Customized

Name: Cat5e CAT6 Networking Cable for Customized
Brand: all-electronics-online.com
SKU: 803521095
Availability: InStock
Rating: 4.7 (127 reviews)

Price:	US $ 11.5/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

4pairs x 0.50mm BC/CCS/CCA conductor+0.90mm PE insulation + Aluminum foil + 0.50mm

Specification

Part Number		Utp cat5e	Utp cat6	FTP CAT.5E
Conductor	Diameter	0.51±0.01	0.574±0.01	0.515±0.01
	Material	Bare Copper	Bare copper	Bare copper
	Type	Solid	Solid	Solid
Dielectric(Insulation)	Diameter	0.91±0.01	1.04±0.01	0.93±0.01
Dielectric(Insulation)	Material	Solid PE	Solid PE	Solid PE
Shielding	Material	-		Aluminium foil Tinned copper drain wire
Shielding	Coverage	-	-	100%
Jacket(sheath)	Diameter	5.1±0.1	6.3±0.01	5.5±0.01
Jacket(sheath)	Material	Flame retardant PVC	Flame retardant PVC	Flame retardant PVC
colors		Pair 1 : Blue,White / Blue Pair 2 : Orange,White / Orange Pair 3 : Green,White / Green Pair 4 : Brown,White / Brown	Pair 1 : Blue,White / Blue Pair 2 : Orange,White / Orange Pair 3 : Green,White / Green Pair 4 : Brown,White / Brown	Pair 1 : Blue,White / Blue Pair 2 : Orange,White / Orange Pair 3 : Green,White / Green Pair 4 : Brown,White / Brown
Number of Pairs		4pairs	4pairs	4pairs
Weight (kgs/km)		30	40	35
Attenuation(10MHz dB/100m)		6.5	5.6	6.5
NEXT (100MHz dB/100m)		≥35.3	≥38.3	≥35.3
ELFEXT (100MHz dB/100m)		≥23.8	≥19.8	≥23.8
RL (100MHz dB/100m)		≥20.1	≥17.3	≥20.1
Impedance (ohms )		100	100	100
Operating Temperature Range(°C)		-20 to 75	-20 to 75	-20 to 75
package		305meters/roll	305meters/roll	305meters/roll

The advantages of our company:

1) Our company is a professional supplier of various kinds of cables for over 20 years.

2) The quality of our products are guaranteed. They are all with CCC, CE, CB, and RoHS certificates.

3) The price is averagely 10%~20% lower than the other competitors.

4) Huge Inventory Allows Us To Ship Your Order Immediately

5) Our employees are all capable and professional. They can offer you the Prompt Courteous Service.

6) We have rich experiences in exporting to overseas.

Package:

1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2) Outer packing:carton box, pull box, wooden case
3) Other packing requirement according to client's' request

WELCOME TO CONTACT ME:

Prod Model:	utp/ftp
Type:	Insulated
Conductor Type:	Solid
Application:	Overhead
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	RoHS
Brand:	Gemt

Gemt Cable Co., Ltd., is a professional supplier of Power Cable, Coaxial Cable, Data Cable, Video Cable, HDMI Cable, Wire Cable, LAN Cable, Communication Cable, Electric Wire, Electric Cable, XLPE, Networfking Cable, Alarm Cable. Located in Yantian Village, Fenggang Town, Dongguan City, China. Mainly engaged in Wire & Cable's manufacture. It is integrated with R & D, Purchase, Manufacture, Promotion and Marketing.

The company has advanced production lines and inspecting equipments. With a group of professional engineers, by strictly following to GB and IEC standards and carry out ISO90001 rigorously, all products produced in this factory is pass the CCC, CE CB RoHS Certifications.

Our tenet is "Specialized quality, Sincere service",

From customers' interest, we are dedicated to provide the high quality products and first-class after-sale service, Since all brands that belong to our company enter into market, they are receiving a lot of user's trust and praise

Base on the persisting dedication of Gemt staff, the company will continue to convergence of the industry technology, management, marketing and other elites, dedicated to the development of power industry, as always, join hands in creating a brilliant tomorrow!
