Cj Intellgence Digital Temperature Control Instrument (XMTG-818(J))

Prod Model:	XMTG-818(J)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	48*48

Product Description

I.Survey:
XMT*-808(J) intellectual ability temperature regulator series controlled by single chip, free input multi-signals of thermocouple, thermoresistance,movement with hand, ON/OFF control and PID control,they are widely used in the automatic control system of the temperature, chemical, ceramics, light, metal, petrochemical and heat treatment industry.
II.Main technical specification:
Basic deviation:±0.5%F.S±1B
Cold end compensating deviation:≤±2.0ºC
Sampling cycle:0.5S
Control cycle: relay output 2~120s and can be adjusted
Relay output contact capacity: AC220V/5A(resistance load)
Driving solid relay signal output:driving electric current≥15mA,voltage≥9V
Power: AC85V~242V(switching supply), 50/60Hz,or the other special request.
Working condition: temperature 0~50.0ºC, relative humidity≤85%RH, without corrode and strong electric radiation.
III.Model Sense:
           XMT _     8      _     8      _     (J)
                   (1)  (2) (3) (4)  (5)
(1) Meter faceplate and Installation dimension(mm):
Blank: 160×80×130  156×76;   A: 96×96×110   92×92;    D: 72×72×110    68×68;
E: 48×96×110   44×92;    F: 96×48×110   92×44;    S: 80×160×130   76×156;
G: 48×48×110      44×44
(2)Design serial number
(3)Alarm: "0": no set alarm       "1or2": one alarm   "3": two group alarm     "5": voice alarm
(4)Input signal: "8": Free exchange of the input signal
Control method:'blank':relay contact output;  'G':Solid state adjustment output;
