Cjx2-K (LC1-K) AC Contactor
| Price: |
US $ 1.55-1.7/Piece |
| Trade Terms: |
FOB,CFR |
| Min Order: |
200/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
CJX2-K(LC1-K) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Cjx2-K(LC1-K),Cjx2n-K(LC2) |
| Rated Operation Voltage: |
380, 660V |
| Rated Operation Current: |
20A |
| Max. Power Of 3 Phase: |
1.5-7.5kw |
| Electrical Life: |
200000times |
| Operation Frequency: |
AC-3 1200t/H AC-4 |
| Place Of Origin: |
Zhejiang, China (Mainl) |
Product Description
CJX2-K(LC1-K) ac contactor 50a, China Top 500, 26 Years Experience
CJX2-K series AC Contact is suitable for using in the circuits the rated voltage up to 660VAC 50HZ or 60HZ, rather current up to 12A in AC-3 using category, for making & breaking, frequently starting & controlling the AC motor. Combine with the auxiliary contact block, timer delay & machine-interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter. With the thermal relay, it is combined into the electromagnetic starter. The contactor is produced according to IEC60947-4.
For motor control, from 6 to 12A(AC-3)
For the control of distribution circuits, up to 20A(AC-1)
Control circuit: A. C or D. C. And it is suitable for using in LC1-K/LC2-K/LP1-K/LP2-K
Standard power rating of 3-phase motors 50/60Hz in category AC-3 220V 380V 660V 230V 400V 415V 440V 500V 690V | Rated operating current AC-3 AC-1 up to 40C 440V | Rated nonconductive voltage | Instantaneous auxiliary contacts | Reference |
| KW | KW | KW | KW | KW | KW | A | A | V | | |
| 1.5 | 2.2 | 2.2 | 3 | 3 | 3 | 6 | 20 | 690 | 1- | CJX2-K0610/NZ/ZN |
| -1 | CJX2-K0601/NZ/ZN |
| 2.2 | 4 | 4 | 4 | 4 | 4 | 9 | 20 | 690 | 1- | CJX2-K0910/NZ/ZN |
| -1 | CJX2-K0901/NZ/ZN |
| 3 | 5.5 | 5.5 | 4 | 4 | 4 | 12 | 20 | 690 | 1- | CJX2-K1210/NZ/ZN |
| -1 | CJX2-K1201/NZ/ZN
|
