Prod Model: |
683090-2000mAh |
Discharging C Rate: |
Over 35c Continuous, Over 70c Burst |
Charging C Rate: |
3c~8c |
Extra Run Time: |
Over 500 Times |
Charging Temperature: |
0 C ~ +45 C |
Operating Temperature: |
-10 C ~ +70 C |
Precision-Balanced: |
High Standard Matching Cells |
OEM Provided: |
Yes |
Type: |
Lithium-Polymer Battery Pack |
Connection Mode: |
Customize |
Standard Voltage: |
3.7V |
Usage: |
Consumer Electronics |
Electrolyte: |
Lithium Cobalt Oxide |
Product Description
Consumer Electronics CE UL2000mAh 3.7V 1c Lithium Polymer BatteryCharacteristics:
1) Endurance capability
2) High voltage
3) Low internal impedance
4) Long service life
5) High Temp.Capacity: | 2000mAh |
Voltage: | 3.7V |
Wh: | 2.0Wh |
Dimension: | 6.8*30*90MM |
Discharging C Rate: | 1C continuous, 2C burst |
Charging C Rate: | 0.2C~1C |
Extra Run Time: | Over 500 times |
Charging Plug: | JST/Molex/ Selected |
Discharging Plug: | JST/Molex/ Selectable |
Technology: | Korean tech, Nano tech, High voltage tech |
Charging temperature: | 0 C ~ +45 C |
Operating temperature: | -10 C ~ +70 C |
Precision-balanced: | High standard matching cells |
Application: | Consumer Electronics |
Others: | Higher MP(Medial Platfo of Voltage), thinner |
Certificates: | ROHS, UL, UN38.3, CE |
OEM provided | Yes |
Warranty
SHIDA BATTERY TECHNOLOGY will be responsible for replacing the cell against defects or poor workmanship for 12 months from the date of shipping. Any other problem caused by malfunction of the equipment or mix-use of the cell is not under this warranty.
Cautions:
1.The aluminum packing foil is very soft that it will be easily left scratches. Please do not hit the cell with any sharp edge parts.
2.Don't fall, hit or bend the battery. It may cause fire or explosion.
3.Short circuit the battery is strictly prohibited; it may damage the battery seriously.
4.Never disassemble the battery. It may cause fire.
5.Never dispose of the battery in fire. It is very dangerous and strictly prohibited.
6.To immerge the battery into liquid such as water is strictly prohibited.
7.Avoid vibration, shock or extrude the battery. Handle carefully when moving it.
8.Storage for a long time If the cell is kept for a long time(3months or more), It is strongly recommended that the cell is preserved at temperature range(0-25oC),low humidity, no corrosive gas atmosphere.
More information,contact us
1. Company Profile:
Shida Battery established in 1996, specializes in design, manufacturing and marketing of high quality Lithium Polymer Batteries.
1) Factory: Covers 60, 000 square meters.
2) Workers: Over 2, 000 persons.
3) Over 220 R&D technical engineers and technicians
4) Daily production capacity: 1500, 000 Ah
5) Certificates: ISO9001: 2000, UL, CE, IEC62133
6) Production and QC equipment: Advanced machines and equipment with high pension.
2. Products Characteristics:
1) Endurance capability
2) High discharging plaform
3) Low internal impedance
4) Long service life
3. Products Applications:
1) R/C planes, R/C cars
2) Drones, Helicopters
3) Power tools
4) Jump starts
5) Other High-Rate electronic products
4. R&D and Quality Management
We hold ISO 9001 certification covering all aspects of our organization, from R&D of the product to the final manufacturing process.
5. Innovation
Shida actively participates in Innovation through relationships with academic and industrial partners, in order to improve innovation efficiency. The continuous improvement of our engineering processes allows us to develop products with better value and performance to market and keep pace with industry's rapidly changing needs.
6. Sustainability
We invest in the developments of green technologies and all Shida products go through an Eco Design process, identifying environmental impact in terms of energy efficiency, hazardous substances, take-back and recycling and lifetime reliability.
