Product Description
We are a leading manufacturer of rock drilling tools, like DTH hammers and bits, DTH drill pipes, RC hammers and bits, tophammer button bits, coupling, cross bits, drill rods located in Germany, China(joint-venture).
We have rich experience in this field of DTH hammers and bits for 60 years.
Owing to high quality, professional serivce and competitive price, we have gotten good reputation from our customers from all over the world, such as US, Canada, France, Spain, Italy, South Africa, Iran, Malaysia, Australia, etc.
Core Orientation Downhole Camera for Down Hole Survey Instruments
Introductions:
ROSCHEN RS-10 model undersized Gyro-inclinometer is the third generation gyro system newly developed, it's a multipoint directional gyro system. The characteristic of the third generation gyro system is that the outside diameter of external tube of pressure resistance is only 38mm, if the heat shield is added, the outside diameter is 45mm, which make the gyro system's measurement range become larger and the temperature accommodation become wider.
Meanwhile it can take a resurvey of the course of the hole as well as a directional parameter survey of the cutting window of casing and sidetrack under a circumstance of magnetic interference.
2. Application
(1) Whipstock-orientation, old wells sidetracking.
(2) Oriented perforating for production engineering.
(3) Cluster wells oriented, for directional survey under the environment of magnetic interference which may produced by the adjacent wells.
(4) Trajectory retest, borehole trajectory measurement inside of the casing.
3. Main Features
(1) Using the advanced flexible rate gyroscope and flexible quartz accelerometer as the survey probe resulted in speedy survey and accurate data.
(2) Mathematical search for north and real time survey without any surface reference. The model is integrated; the minor angle measurement data is also trusted worthy, real-time measurement and record.
(3) Automatic drift correction.
(4) Better measurement adaptability, large temperature measurement range, strong compact ROSCHEN resistance, it can measure either large wellhead or small wellhead.
(5) Start up promptly, semi continuously measuring, measuring rate rapidly.
(6) Providing magnetic measurement, keeping away from the connecting parts when cutting window of casing.
(7) Survey the depth through guiding cable winch depth.
(8) Providing two types of 1 3/4'' and 1 3/8" for directional key seat survey.
(9) Simple operation, convenient use and high reliability.
4. Main Technical Characteristics
(1) Parameters surveyed:
Inclination angle, azimuth angle, northward tool face, gravitational tool face and bottom hole temperature (BHT).
(2) Accuracy of survey:
Inclination angle of well: 0°~50° ≤±0.15°
50°~70° ≤±0.2°
Azimuth: 0~360° 1σ ≤ ±1.5°
Gravitational tool face angle: 0~360° ≤ ±1.5°
Northward tool face angle: 0~360° ≤ ±3°
(3) Ambient conditions adaptability:
Temperature tolerance: without heat shield 100ºC
with heat shield: 175ºC
Pressure resistance: 140MPa
Impact resistance: 700g, 0.5ms, 1/2Sine
(4) Physical dimension External diameter of the detection tube:
without heat shield 38mm with heat shield 45mm
Length of the detection tube: 1300mm
Length of the centralizer: 400mm
Length of heavy bars: 900mm, 1500mm (optional)
Standard R or E model guide shoe
(5) Survey software:
V2.0.0.0 Windows System
(6) Survey type and time:
Trajectory survey: Pro-continuous, one point per minute
Direction survey: single point or multipoint
(7). Surface control system:
Wire/ gyro compatible control system.
FAQ
Q: Are you a manufacturer or trading company?
A: We are a specialized manufacturer.
Q: What are your main products, and used for?
A: Our products include core bit, PDC bit, reaming shell, core barrel, casing, drill rod, SPT equipment, Shelby sampler, drill rig and other drilling parts.
They are used for mineral exploration, geological drilling, geotechnical engineering and soil sampling.
Q: How about the delivery terms?
1. Payment: T/T, L/C, Western Union, Paypal, 30% deposit in advance and rest before delivery.
2. Min. order quantity: 1 piece.
3. Transportation: By DHL/TNT/Fedex express, air, sea, train.
Q: How about discount?
A: Price is based on products and order quantity.
Q: Do you accept sample order?
A: Yes sure, please contact us for details.
Q: How about your after-sales service?
A: As a manufacturer, we offer promt technology support for all problems and questions. Besides, we accept goods return or replace for quality problem.
Q: How does your company control the quality?
A: Quality first. In order to guarantee high quality for our products, Roschen always makes a serious inspection for all products and raw materials in strict procedure. We have obtained certificate of ISO9001:2000 in 2004.
