Custom PCBA Factory Circuit Board PCBA Inverter for Air Conditioners
Price: |
US $ 0.42-0.56/Piece |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,Western Union,Paypal |
Custom pcba factory circuit board pcba inverter for air conditionersProduct DescriptionAdvantages:
1 R&D team support
2 UL, RoHS,ISO9001,SGS
3.IPC class2
4.Advanced production line and promtly delivery.5,Honest Credibility in China.
6.Professional and abundant experience in PCB and PCBA.
7.Competitive price and good quality.
8. Excellent after-sales service.
9. 100% test
PCBA Technology:
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
PCB Manufacturing Capability PCB Manufacture Capability |
Item | Manufacture Capability |
Layers | 1-26 Layers |
HDI | 2+N+2 |
Material Types | Fr-4, Fr-5, High-Tg, Aluminum Based , Halogen Free, |
Isola, Taconic, Arlon, Teflon, Rogers, |
Max. Panel Dimension | 39000mil * 47000mil (1000mm * 1200mm) |
Outline Tolerance | ± 4mil (± 0.10mm) |
Board Thickness | 8mil-236mil (0.2 - 6.0mm) |
Board Thickness Tolerance | ± 10% |
Dielectric Thickness | 3mil-8mil ( 0.075mm-0.20mm) |
Min. Track Width | 3mil ( 0.075mm ) |
Min. Track Space | 3mil ( 0.075mm ) |
External Cu Thickness | 0.5 OZ - 10 OZ ( 17um - 350um) |
Internal Cu Thickness | 0.5OZ - 6OZ ( 17um - 210um) |
Drilling Bit Size ( CNC ) | 6mil-256mil ( 0.15mm - 6.50mm) |
Finished Hole Dimension | 4mil-236mil(0.1mm - 6.0mm) |
Hole Tolerance | ± 2mil (± 0.05mm) |
Laser Drilling Hole Size | 4mil(0.1mm) |
Aspect Ration | 16: 1 |
Solder Mask | Green, Blue, White, Black, Red, Yellow, Purple, etc. |
Min Solder mask Bridge | 2mil(0.050mm) |
Plugged Hole Diameter | 8mil-20mil ( 0.20mm-0.50mm) |
Beveling | 30o - 45o |
V-scoring | +/-0.1mm, 15o 30o 45o 60o |
Impedance Control | Min. 5% General ± 10% |
Surface Finishing | HASL, HASL(lead Free), Immersion Gold |
Immersion Silver, OSP, Hard Gold ( up to 100u" ) |
Certification | UL RoHS ISO9001: 2000 ISO14000: 2004 SGS |
Testing | Flying probe, E-TEST, X-RAY Inspection , AOI |
Files | Gerber Protel DXP Auto CAD PADS OrCAD Express PCB etc |
Apply to
1. Consumer electronics.
2. Industrial control.
3. medical instrument.
4. fire service implement etc.
Our Service:
1.Reply your enquiry in 2 working hours.
2.Experienced staffs answer all your questions in fluent English.
3.Customized design is avaliable OEM&ODM are welcomed.
4. Exclusive and unique solution can be provide to our customer by our well-trained and professional engineers and staffs.
5. Special discount and protection of sales area provided to our distributor.
PCB prototype Lead time:PCB Prototype Lead Time: |
item | General time | Quick Turn |
1-2 | 4 days | 1 days |
4-6 Layers | 6 days | 2 days |
8-10 Layers | 8 days | 3 days |
12-16 Layers | 12 days | 4days |
18-20 Layers | 14 days | 5 days |
22-26 Layers | 16 days | 6 days |
Note: Base on all data received by us and must be complete and problem free, Lead time is ready to ship time. |
FAQ
Q1: What's your minimum order quantity?
A1: Our MOQ is not the same based on different items. Small orders are also welcome.
Q2: what file we should offer?
A2: PCB:Gerber file is better,( Protel ,power pcb,PADs file), PCBA : Gerber file and BOM list.
Q3: What any other information should be offered except for file?
A3:Following specifications are needed for quotation:
a) Base material
b) Board thickness:
c) Copper thickness
d) Surface treatment:
e) color of solder mask and silkscreen
f) Quantity
How to Contact Us? Would like to know more about the product? Please feel free to contact us
Cellphone:+8618025363502
Prod Model: |
As 021 |
Voltage: |
DC12V |
Certificate: |
RoHS, ISO9001:2008, SGS, UL |
Impedance Control Tolerance: |
10% |
MOQ: |
1PCS |
Layer: |
1 - 16 Layer |
Solder Mask Colour: |
Green, Blue, White, Black, Yellow, Red |
Surface Finish: |
HASL, Enig, OSP, Gold Finger |
Min Space: |
0.1mm |
Min Hole Location Tolerance: |
±0.075mm |
Surface Finishing: |
Lead-Free HASL |
Metal Coating: |
Silver |
Layers: |
Multilayer |
Base Material: |
FR-4 |
Certification: |
UL |
Customized: |
Customized |
Condition: |
New |
Mode Of Production: |
SMT&DIP |
Fastline is a Leading PCB manufacturer in China. It was found in 2003, serving customers in over 40 countries from various electronic industries, Over 70% of products are exported to America, Europe and other Asia Pacific countries.
Fastline could meet all your PCB manufacturing needs, including High multilayer PCB, Aluminum based PCB, HDI PCB, Rigid-flex PCB, heavy copper PCB, and PCB assembly as well. Our products are widely applied in telecom, industrial control, power electronics, medical instrument, security electronics, aerospace and so on.
And provides "PCB One-stop PCB solution" to meet customers' diverse demands.
Our factories with a facility area of more than 40, 000 square meters with 1000 professional staff, And we have got the approval of ISO9001 certificates. ULCertification and all Products Meet RoHS compliance.
Fastline Circuits is commited to provide superior quality products and services that consistently meet and exceed our customers requirements on time, every time!
