Disconnectors for Metal- Oxide Surge Arrester

Name: Disconnectors for Metal- Oxide Surge Arrester
Brand: all-electronics-online.com
SKU: 120008387
Availability: InStock
Rating: 4.5 (124 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	500/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	TL-1
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Disconnector:	Surge Arrester
Application:	High-voltage
Material:	Composite Polymer
Structure:	Disconnectors
Color:	Black
Brand:	Haivol
Type:	Arrester

Product Description

Disconnectors for Metal- Oxide Surge Arrester
Disconnectors for Metal- Oxide Surge Arrester (IEC60099-4)
Arrestor disconector is a device for disconnecting an arrestor from the system in the event of arrestor failure. To prevent a persistent fault on the system and to give visible indication of the failed arrestor. TL-1 is a thermal explode disconector.
Main Technical specification:
Standard: IEC60099-4
Square wave current Withstand capacity 2mS: 600A
Impulse current Withstand capacity 4/10μ S: 100KA
Performance characteristic: 2A--5S; 20A_0.5S; 200A_0.05S

Haivo Electrical Co., Ltd, is a provider of power equipment and services for the global electric utility industry. It mainly manufacture power transmission & distribution equipments, covering many product series as Fuse cutout, Surge arrester, Composite & Porcelain insulator, Disconnector switch & Load Break Switch, Hardware fitting for overhead line, Cable accessories and Cable kits (cold & heat shrinkable cable accessories).

HAIVO ELECTRICAL, As one of the international electrical companies in China, We not only manufacture the power equipment, but also provide sustainable power solutions underpinned by technology innovation. To date, HAIVO conducts business in nearly 50 countries and territories in South America, Europe, Latin America, Asia, Africa, and the Middle East. HAIVO′ S high standards have received due recognition from the local power customers.

HAIVO′ S worldwide operation and sales coverage is backed by exceptional experience and expertise to provide customers with the most reliable and highest quality products and services available.

For the quality control system, HAIVO was successively awarded ISO 9001: 2008 by DAS CERTIFICATION Ltd & UKAS QUALITY MANAGEMENT, and TYPE TEST REPORT by China NATIONAL HIGH VOLTAGE APPARATUS QUALITY SUPERVISION TESTING CENTER(XIHARI) & QUALITY INSPECITION AND TEST CENTER FOR EQUIPMENT OF ELECTRIC POWER.

We promise we will offer first-class quality, reasonable price, first-class service and following the business philosophy of development and innovation to serve global power customers!
