Double Sided PCB Board for Industry Area

About us:
Our company was established in 1992 with about 3,000 employees,total land area up to 101,000m², and floor area up to 81,000m². We specialize in PCB manufacturing for more than 20 years.

With foresight management, we insist on "providing excellent quality products". We provide nearly error-free products and overall structured service in order to satisfy customer's needs.

What products and services we offer:

Excepting OEM PCB, i.e. Telecommunication, PC Add-On Card, IT Application, Network Device, Multi Layers FR-4 product, we have some outstanding products as follows:

1. Carbon Built on PCB:Apply for Thick Film Technology to make the PCB with buried resistors or touch pad function.
2. Thin PCB:Less than 16 mil thickness in 4 or 6 layers FR-4 production is another challenge for our production capability.
3. CSP // BGA PCB:Those kinds of PCB are increasing and we expect the quantity will be over 10% of our production in coming years.
4. Special Service: In addition to devote in normal PCB process, our engineering team also provide design support as requested by clients

Year Item	2015	2016E
		Mass Production	Sample
Max. Multilay ers	20	20	24
Board Thickness Tolerance (mil/mm)	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);
Min. hole size (mil)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 3.5mil (0.089 mm)
Finished Aspect ratio	12:1.	12:1.	16:1.
Min. line Width/Space (mil)	2.0/2.0mil; (0.050/0.050 mm)	2.0/2.0mil; (0.050/0.050 mm)	1.6/1.6mil;(0.040/0.040mm)
Impedance (ohm)	+/-10%	+/-10%	+/-7%
Dif f erential Impedance (ohm)	+/-10%	+/-10%	+/-7%
Gold Finger thickness(u"/um)	80u" (2um)	80u" (2um)	80u" (2um)
Router tolerance	±3.0mil (0.076mm)	±3.0mil (0.076mm)	±2.0mil (0.051mm)
Surf ace treatment	ENIG,H/G plating,OSP,Immersion sliver		ENIG,H/G plating,OSP,Immersion sliv er,Immersion Tin,ENEPIG
Application / Lamination
Standard and extended	FR4(TG140-180°),ANTI-CAF,Halogen Free, Low z-axis expansion(Lead Free)
Special perf ormance	High TG(BT)		High TG(BT),Low loss,FPCB material
High f requency	PTFE,Ceramic

 Before quote, please offer:

1. Gerber file
2. Base material: FR4/ AL/ FPC/ CEM-1/ CEM-3/ 94v0/ Rogers
3. Board thickness:
4. Surface treatment
5. Copper thickness
6. Color of solder mask and silkscreen
