Ecoographix High Speed Thermal Platesetter CTP for Offset Printing
| Price: |
Negotiable/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
The most cost-effective offline thermal CTP model: Ecoosetter T-400S, your Right Choice
Configurations:| Model | EcooSetter T-400SA CTP | Weight | 1000 kgs |
| Image system | 32 channels | Size | 1600mm*1410mm*1120mm |
| Throughput | 22 plates per hour | Power Supply | Single phase:220AC, +6%, -10%, Power consumption:4kw |
| Repeatability | ±5μm | Environment | Recommended:21-25ºC, max:18-26ºC, humidity:40-70% |
| Plate thickness | 0.15mm to 0.3mm | Laser type | semiconductor laser |
| Resolutions | 2400 dpi | Laser wavelength | 830 nm |
| Plate size(max) | 800mm*660mm | Plate size (min) | 400mm*300mm |
| Plate loading | Semi Automatic | Brand | Ecoographix or OEM |
Related images
Other options for this model| Model | T-400 S | T-400 E | T-400 F | T-400 FA | T-400 EA |
| Imaging system | 32 Channel | 24 Channel | 48 Channel | 48 Channel | 24 Channel |
| Throughput | 22 PPH | 16 PPH | 28 PPH | 28 PPH | 16 PPH |
| Plate loading | Manually | Manually | Manually | Semi automatic | Semi Automatic |
Delivery & Package
Any kinds of transpotation is workable for us. The nearest departure port is Shanghai port or Ningbo Port.
The equipment is packed in standard wood carton for exporting use with enough protective layers.
Q&A1. How long is the lead time?The lead time for each CTP machine is normally 30 days. We can accelerate for emergency cases.
2. How long is the warranty period?
Ecoographix gurantees 2 years of warranty for laser head and spare parts.
3. Is there any certification for your CTP machine?
Yes, All our CTP machines have been certified by SGS and CE.
4. Do you have accompanying plate products to make an easy purchase for some end users?
Yes, we have qualified CTP/CTcP plates at most favourite price. In addition, blanket, ink, developer, processors are also in our business range.
5. What is your normal Payment term?
Normally, 30% deposit, 70% before shipping.
6. What are your main products ?
Generally, we manage two types of products: prepress equipments and consumables, postpress equipments and consumables. Our category is as below:1. Prepress machines and consumables, including CTP machine, flexo CTP machine, ink, developer, processor, CTP/CTCP plate and blanket.2. Postpress equipment, including die cutting machine, automatic punching machine, book binding machine, carton erecting machine, paper cone cup machine, automatic folder gluer.7. Can you offer some successful installation for reference?Yes, we achieve great success in USA,Canada,Mexico,Colombia,Turkey,Hungary,South Africa, etc, with the great assisstance of our dealers. If you have any concern about the quality or service, you can contact them by your own.8. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V9.
9. What about the Installation and after-sales technician support?
Our engineer are all Ecan go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions,we will be at your disposal 7x24 hours.
10.Where is your factory?
Our CTP machine factory is located in Hangzhou city , which is about 1.5 hour by train from Shanghai.
You are warmly welcomed to visit our factory at any time!
| Prod Model: |
EcooSetter T-400 SA |
| Weight: |
1000 Kgs |
| Power Supply: |
4 Kw |
| Usage: |
Offset Printing |
| Plate: |
Lithography Printing |
| Type: |
CTP Plate Making Machine |
| Light Source: |
Semiconductor Laser |
| Certification: |
SGS |
EcooGraphix., also known as Konita Digital, is a leading digital Pre-Press solution provider who places great emphasis on research and development, systems integration and technical support. EcooGraphix supplies customers worldwide with integrated solutions that include Pre-press machines: Thermal CTP and UV CTP Imaging Equipment, Printing Plates and Consumables and also some Post-press machines: Perfect Binder, Carton Erecting and Die cutter, with Technical Service Support.
Our Vision is to become an international market leader within the Pre-Press and Printing Industry.
Through Professionalism, Innovation, Efficiency and Superior Products we hope to achieve this goal.
EcooGraphix Thermal CTP and UV CTP Machines have gained a reputation for high quality engineering and reliability, incorporating market leading design features.
EcooGraphix Thermal CTP and UV CTP Printing Plates are regarded as being one of the world's top brands for quality and consistency.
EcooGraphix has established international partnerships of reliable Agents with technical ability. Significant successes have been achieved in countries such as the USA, Canada, Mexico, Chile, UK, Hungary, Turkey, South Africa, Greater Africa and China. With an average annual growth of 50% in the last three years, EcooGraphix is quickly gaining international market share and recognition.
EcooGraphix has teams of internationally experienced technical experts and professionals drawn from the Printing Industry. We can offer tailored solutions to Commercial, Packaging and Newspaper Printers as well as Output Centres with non-stop technical and consulting support.
With a deep and profound knowledge of both the China and International Printing Industries, EcooGraphix is well positioned to become the supplier of choice for quality Pre-Press and Post-press Products to the Printing Industry worldwide.
