EH Contactor (EH170)

Prod Model:	EH170
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Communication Relay
Theory:	Thermal Relay
Size:	Miniature

Product Description

EH series AC contactors is mainly used in the electric power circuit of AC 50Hz or 60Hz, rated voltage to 660V, current to 800A for making and breaking circuit, and it can be formed into motor starter with thermal relay or electronic protector for protecting from overload circuit.

The Specifications as follows:

EH80 EH90 EH100 EH145 EH175 EH210 EH260 EH300 EH370 EH550 EH700 EH800.

We are producing EH contactor in high quality! !


EH series AC contactors is mainly used in the electric power circuit of AC 50Hz or 60Hz, rated voltage to 660V, current to 800A for making and breaking circuit, and it can be formed into motor starter with thermal relay or electronic protector for protecting from overload circuit.

The Specifications as follows:

EH80 EH90 EH100 EH145 EH175 EH210 EH260 EH300 EH370 EH550 EH700 EH800.

AC Contactor Series:

EH		6	9	12	16	25	32	40	50	63	75
Ui V		690
Ith A		20	26	28	28	45	65	100	125	125	125
Ue V		220
		380
		660
Under Interruption Period Operation System le (A)	AC-1	20	22	24	28	45	55	70	100	115	125
	AC-3	6 6	9 9 5.5	12 12 7	16 16 7	25 25 15	30 30 17.5	40 40 28	50 50 38	63 63 46	75 75 55
	AC-4	6 6	9 9 5.5	12 12 7	16 16 7	25 25 15	30 30 17.5	40 40 28	50 50 38	63 63 46	75 75 55
AC-3 Pe Kw		1.5 2.2	2.2 4 4	3 5.5 5.5	4 7.5 5.5	6.5 11 11	9 15 15	11 18.5 22	15 22 30	18.5 30 37	22 37 45
Non-interrupt Operation Ie(A)		20	22	24	28	45	55	70	100	115	125




EH		80	90	100	145	175	210	260	300	370	550	700	800
Ui V		690
Ith A		145	160	200	230	260	300	400	445	550	800	1000	1000
Ue V		220
		380
		660
Under Interruption Period Operation System le (A)	AC-1	145	160	200	230	260	300	400	445	550	800	1000	1000
	AC-3	80 80 65	90 90 70	120 120 120	145 145 120	185 185 170	210 210 210	260 260 250	305 305 280	400 400 370	550 550 550	700 700 700	750 750 750
	AC-4	80 80 30	80 80 35	117 117 47	125 125 55	146 146 66	175 175 55	250 250 95	250 250 95	350 350 117	450 450 140	630 630 185	630 630 185
AC-3 Pe Kw		22 40 45	22 45 59	30 55 110	45 75 110	55 90 132	59 110 160	80 140 200	90 160 250	110 200 355	160 280 500	220 370 600	220 400 650
Non-interrupt Operation le(A)		145	160	200	230	260	300	400	445	550	800	1000	1000
