Electrical DC Current and Voltage Transducer

Name: Electrical DC Current and Voltage Transducer
Brand: all-electronics-online.com
SKU: 672679941
Availability: InStock
Rating: 5 (26 reviews)

Price:	Negotiable/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FUD-DI/DU
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Class:	0.2
Weight:	240g
Size:	55mm X 75mm X 120mm
Working Temperature:	0~40'c

Product Description

FUD-DI/DU ELECTRICAL DC CURRENT AND VOLTAGE TRANSDUCER

FUD-DI/DU electrical DC current and voltage transducer change the measured signal to a DC current / voltage output according to the linear scale; excellent temperature characteristic and good working stability, configuration compactness and briefness.

FEATURES
DC voltage transducer
DC current transducer
Accuracy class can reach 0.2%
DC input range can be customized
DC output range can be customized

PARAMETERS

FUD-Type-Input-Power Supply-Output
Type	DI: DC current transducer DV: DC voltage transducer
AC input	A1: 0-75mA, A2: 0-100mA, A3: 0-±75mV, A4: 0-±100mV, A5: 0-20mA, A6: 4-20mA, A7: 0-5A, A8: 0-15A, V0: 0-5V, V1: 0-30V, V2: 0-60V, V3: 0-300V, V4: 0-400V, V5: 0-450V, Vn: User define.
Power supply	P1: AC110V±10%, P2: AC220V±15%, P3: AC110V-330V.
DC output	O1: 0-5V, O2: 1-5V, O3: 0-20mA, O4: 4-20mA, O5: 1-3-5V, O6: 4-12-20mA.
Example 1: FUD-DI-A2-P2-O4
FUD series DC current transducer	Input: DC 0-100mA Power supply: AC220V±15% Output: DC4-20mA
Example 2: FUD-DU-V3-P2-O4
Details: FUD series DC voltage transducer	Input: DC 0-300V Power supply: AC220V±15% Output: DC4-20mA
Please check the type, input range, output range and power supply when your order the product.

TECHNICAL INDEX

Technical Index
Standard	QB/441600 17 079-2001
Accuracy	0.2%, 0.5%
Consumption	≤3VA
Accuracy drift	Annual variation < 0.2%
Insulation voltage	AC 2kV/min.1mA (Between input- output / power)
Insulation resistance	≥20MΩ (DC500V)
Surge voltage	5KV (Peak value), 1.2/50μs
Response time	≤350ms
Input range	AC 0-10A ,AC 0-500V(Option)
Absorbed power	≤0.1VA
Overload	Current: 2 times continuous, 20 times /1s; Voltage: 2 times continuous
Load resistance	Current output: RL≤550Ω
Load resistance	Voltage output: RL≥2kΩ
Working environment	Temperature: -10 to +50ºC
Working environment	RH: 20-90%, without condensation
Storage conditions	Temperature: -40 to +70ºC
Storage conditions	RH: 20-95%, without condensation
Installation	35mm DIN sliding-way or M4 screws
Dimension	55mm x 75mm x 120mm
