Electrical Insulating Paper 6631 Dmdm

Name: Electrical Insulating Paper 6631 Dmdm
Brand: all-electronics-online.com
SKU: 703239482
Availability: InStock
Rating: 4.7 (131 reviews)

Price:	US $ 2.7kg
Trade Terms:	FOB,CFR,CIF
Min Order:	800kg
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

6631 DMDM insulation paper

6631 DMDM insulation paper is four-layer flexible insulation material consisting of polyester fleece- polyester film - polyester fleece. The used adhesive is acid-free and temperature resistant. It has excellent electrical and mechanical properties.

The PET fleece is porous and absorbs resin when impregnated. It can be used as slot and phase insulation in low voltage machines or as interlayer insulation in transformers. It enables easy processing on handwork.
DMDM(6631) class B. It has good mechanical strength, dielectric, and adhesion.
Capable for B series motors and electric appliance as insulation slot, inter-turn insulation and lining insulation. Its heat-resistant is classified as Class B.

Special thicknesses or combinations can be supplied according to our customers.
Products can be supplied in rolls, sheet, tapes and shapes according to customers' requests.

Thickness: 0.10 - 0.40 mm
Roll: width 1000mm
Tapes: from 10mm width upwards
Storage life: 1 year

Properties			Units	Values
Nominal thickness			mm	0.15	0.17	0.20	0.23	0.25	0.30	0.35
Thickness tolerance			mm	±0.02	±0.03	±0.03	±0.03	±0.03	±0.03	±0.04
Grammage and tolerance			g/m2	140±20	190±28	220±33	260±39	300±45	350±52	425±63
Film Nominal Thickness			mm	0.050	0.075	0.10	0.125	0.15	0.19	0.25
Tensile Strength	MD	No bending	N/10mm	≥80	≥120	≥140	≥180	≥190	≥270	≥320
	MD	After bending		≥80	≥105	≥120	≥150	≥170	≥200	≥300
	TD	No bending		≥80	≥105	≥120	≥150	≥170	≥200	≥300
	TD	After bending		≥70	≥90	≥100	≥120	≥130	≥150	≥200
Elongation	MD	No bending	%	≥15					/
	MD	After bending		≥10					≥5
	TD	No bending		≥20					/
	TD	After bending		≥10					≥5
Breakdown Voltage No bending			kV	≥6	≥7	≥9	≥10	≥12	≥15	≥18
Bonding property at room temp.			/	No delamination
Bonding property at 155±2°C, 10 min			/	No delamination, no blister, no adhesive flow
The quality warranty period			Twelve months(under 40°C)

Prod Model:	6631 DMDM
Markets:	Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Thickness:	0.10mm-0.40mm
Width:	1000mm
Heat-Resistance:	B Class 130
Storage Life:	1 Year
Application:	Motor
Type:	Solid
Chemistry:	Inorganic Insulation
Thermal Rating:	B 130
Maximum Voltage:	<10KV
Brand:	Chr

Welcome Xuchang ChengRui Electrical Insulation Material Co., Ltd

If any question, pls contact our sales

Our main products are as follows:

Film Products: 6020/6021 Polyester film, 6051 polymide film

Flexible composite insulation paper: 6630 DMD insulation paper, 6641-F DMD, 6640NMN, 6650NHN, 6520/6521 insulation paper

Insulation binding tape: Alkali-free fiberglass tape, 2840 epoxy resin impregating binding tape, mica tape, cotton tape, shirinkable binding tape,

Insulation Sleeving: 2715 PVC fiberglass sleeving, 2751 silicone fiberglass sleeving, 2753silicone resin fiberglass sleeving, 2740 acrylic fiberglass sleeving.

Impregnating fiber products: 2432alkyd Fiberglass varnish cloth tape, 2310 oil varnish cloth, 2450, 2210

Electrical insulation paper: Insulation paperboard, Diamond Dotted paper, presspaper, crepe paper, cable paper

Laminated sheets: 3021 phenolic paper sheet, 3025phenolic cotton cloth sheet, 3240epoxy fiberglass sheet, 3841 epoxy rod, 3722-1 cloth bar

The products are widely used for slot insulation, interturn insulation, layer insulation and liner insulation of the large and small motor. Some are for binding insulation of transformer, impregnating material, electrical wire and other electrical insulation.
