Electrical Outdoor Switches 11kv Disconnecting Switch
| Price: |
US $ 180/Piece |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,D/P |
11KV medium voltage single pole 630A with porcelain insulators non load break isolator switch
| Specifications: |
| Type | RH-B 11KV/630A |
| Rated voltage | 11KV |
| Rated current | 630A |
| 4s heat steady e.c. | 12500A |
| Shock voltage | 31500A |
| Impulse withstand voltage | 95KV |
| Power-frequency withstand voltage | 42KV |
| Creepage distance | 420mm |
| Isolator switch standard | IEC60694 |
Remarks:
1.Three-pole RH-B type isolator switch can be also provided here.
2.We can provide the RH-B isolator switch voltage rated from 11KV to 36KV,current rated from 400A to 1250A.
3.Polymeric type of isolator switch is also produced here.
Service Conditions of Outdoor gang operated pole switch type :
Altitude:1000 to 3000m.
Ambient temperature:-30 celsius to +40celsius
The relative humidity of air:monthly humidity not more than 90%,daily humidity not more than 95%.
Wind pressure:not more than 700Pa( wind speed is 34m/s).
Amplitude:earthquake degree 8
| Prod Model: |
RH-B |
| Impulse Withstand Voltage: |
95/195 Kv |
| Power-Frequency Withstand Voltage: |
42/80kv |
| Breaking Capacity: |
High |
| Usaga: |
High Voltage |
| Type: |
Switch |
ZHEJIANG FUERTE ELECTRICAL APPARATUS Co., Ltd...(former Wenzhou fuerte Electric Co., Ltd., Zhejiang Yueqing City People's Electric 3 Factory) was founded in 1985. Existing factory building area of 8700 square meters, is a Machinery Industry Ministry,
Ministry of Power Industry and the international integration of production generic "12KV ~38KV" line protection and transformer protection fuse a variety of voltage levels, surge arresters, isolation switch, vacuum circuit breakers, etc. Series of joint ventures. Precarious Twenty-four years, is V Stewart walked one after another through these difficult times. After V Stewart who tenaciously that, with perseverance to carry out independent innovation, the company to overcome difficulties one after another, various series of products have passed the ISO9001 quality system certification, in accordance with international electricity Work IEC291, 282, 644, 787, the State GB/T15166, 15166.2, the United States C37.41, and IEEE standards. And Power Transmission Equipment Industry Association China Branch of the members of high-voltage switching unit, the national standards GB/T15166.6-2008 involved in the drafting unit, the State Quality Supervision and Inspection Center of qualified enterprises, Zhejiang Province, product quality fixed excellence units, Zhejiang, China Construction Bank sub - OK AAA enterprise, Zhejiang Province, Wenzhou City, Yueqing municipal export large, foreign investment, star, key units, and so honor, in order to alleviate the severe employment situation Yueqing City, increasing foreign exchange reserves to make a significant contribution.
Since 2003, the company implemented ISO9001 quality management system certification through the Netherlands KEMA company since the company's chairman and general manager for the first time explicitly to the core leadership team, the detailed planning of a
Sales office at all levels, including at the provincial departments. We are in strict accordance with the requirements of ISO9001 quality management system, procurement, production, supply, service and development of new products and a series of work leading
To a high-quality products available to the community and at the same time with an open mind to their customers about product usage and to collect them opinion, in order to strive for excellence and achieve excellence and to lay a solid foundation for a variety of products annual production capacity of more than 100 million units. "The least bit of skill, achievement of a thousand miles-chi, " V Technology Corporation to
Abundant strength, leading technology, in place of service, reliable quality...All kinds ofseries of brand products in the domestic alternative to imported similar products occupied the commanding height of the market, product sold in the domestic 31 provinces,
Municipalities and autonomous regions. At the same time sold to the Philippines, South Korea, Iraq, South Africa, Argentina, Indonesia, Malaysia, Morocco, Nigeria, Saudi Arabia, Syria, Singapore, and Hong Kong, Taiwan and other countries and regions.
FSC series fuse projects more at the end of 2006 successfully passed the state-level Spark Program project acceptance; In 2007 the company developed a utility model Outdoor AC high voltage fuse jet access to national patents; That same year, my company
Developed a utility model outdoor high-voltage AC isolation switch access to national patents; Man Road Zhenru with big iron, and CHAMC!
V Stewart's achievements can only represent the past, and that the future work also requires our continued efforts to provide the community fine for the country to create wealth. Social progress, development of the times is the eternal theme of the face of increasing competitive pressure at home and abroad, V Stewart will join domestic and foreign merchants, to turn the tide upstream.
