Fiber Optic Sensors - Industrial Control

Name: Fiber Optic Sensors - Industrial Control
Brand: all-electronics-online.com
SKU: 677358685
Availability: InStock
Rating: 4.3 (95 reviews)

Price:	Negotiable/Piece
Min Order:	1 /Piece

Contact Supplier

Showroom Product Company Profile

Model: HY-TT1
Theory: Fiber Optic Sensor
Detect distance: 1~5m;
Size: W25 X H67 X L81 mm
Operating: Light ON/ Dark ON
Protection: IP54 (IEC Standard)
Material: Case: ABS, Lens cover: Acryl,
Response time: Max: 20mS

1. Features:
1) Multiplicity appearance
2) Compact volume
3) High repeat orientation precision
4) Many output form
5) Strong protection distribution
6) High on-off frequency commonly 600Hz
7) Wide voltage range
8) Dustproof, vibration-proof, waterproof and oil-proof
9) With short-circuit protection and inverted connecting protection
10) Service life up to one million
11) Adopts envelope glue, temperature resist, oil-proof colophony in it
12) Limit upgrade product

2. We can supply a complete range of Proximity switches/sensor, Photoelectric switches/sensor, SSR, with full selection of specifications.

3. Our proximity switches covers: Inductance proximity / Capacitance proximity switches, Hall / Mimic linear / Reed / Safety explosion-proof sensors.

We have been focusing on researching\manufacturing and selling of PMMA plastic optical fiber since 2000. Thanks to our strong technical team and after sales service, we have successfully established long term business relationship with customers all over the world. Hope you can be the next one to share this cake with us!

Interested customers, pls feel free to ask.

Parameters	Unit	Numerical value
Fiber diameter	mm	1.0 , 0.5, 0.75
Cable diameter	mm	2.2± 0.1 or 1.0± 0.05
Fiber material	---	PMMA
Jacket material	---	PE
Attenuation	dB/m	≤ 0.2
Insertion loss	dB	< 0.5
NA	---	0.5
Wavelength	nm	650
Incident angle	---	≤ 60°
Bandwidth	MHz· 100m	≥ 10
Cable length	m	1~100m to order
Bend radius	---	≥ 10 times of fiber dia.
Operating temperature	Celsius Degrees	-20~70
Storage temperature	Celsius Degree	-20~70
Refractive index	---	Step index

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output:	Switching Sensor
Usage:	Detecting The Position and Presence of an Object
Theory:	Photoelectric Sensor

Sichuan Huiyuan Plastic Optical Fiber Co., Ltd is a high-tech company which specializes in researching, manufacturing and marketing of low-loss PMMA plastic optical fiber, optical cable as well as its applications.

Launched in 2000, the company had realized the mass production of Low Loss PMMA POF through independent R &D of optical fiber raw materials, manufacturing equipment and production process in 2003, which was recognized as the first success in China. The company's products have broken the monopoly of foreign companies and filled the gaps in the domestic industry. Based on this success, the company had undertaken and accomplished the technological breakthrough task of the National Science and Technology Department, the Industrialization Upgrading Project of the State Development and Reform Commission, and the independent manufacturing of fluorine resin clad material, with the optical attenuation < 0.2dB / m, which has achieved an advanced level among the similar products in the world>.

It has developed the technology of lighting products, and has cultivated a large number of lighting manufacturers and lighting dealers; PMMA POF is widely used in decorative lighting in China.

We are expanding our market to oversea market! Sincerely welcome any contact from dealer in communication and lighting area around the world!
