Float Level Controller (CX-FLM-UQK-12)

Prod Model:	CX-FLM-UQK-12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Install Mode:	Optional
Float Ball Size:	Optional
Temperature:	-20~100c
Switch:	Nc/No
Power Supply:	220V
Accuracy Error:	±2mm (in Water)

Product Description

CX-FLM-UQK-12 Float level controller

Brief introduction
1.The series float level controller used to measure the level of the opening container
2. When the level is higher or lower than the given control level ,it will emit signal through signal equipment . According to this ,it can control the level surface speedy and achieve safety production
3.It is widely used ,cause it can control a large range level ,conveniently usage and installation ,simple structure ,high accuracy ,and economy

Installation
1.Let the horse fix on the related container wall with 4 pieces M8 screw nails  ,
then let the instrument install on the horse

Use the cable to connect the contacts device to the power supply

Main parameters
Range:0.5-20m
Accuracy :±20mm
Instrument weight: 3.0kg
Power :1)The contact device can connect to AC or DN ,the voltage can not exceed 220V .
          2) The contact device allow current 3A
