The working principle of thermal relay is the heat generated by the current flowing into the heating element, the bimetal have different coefficients of expansion deformation, when the deformation when it reaches a certain distance on the push rod moves, the control circuit is disconnected, so that the contactor is power off, the main circuit is disconnected, the motor overload protection. As an overload protection device, the relay is widely used in production, which has the advantages of small size, simple structure and low cost.
Features&Faction:
1, 35a switching capability.
2, 1NC configuration available,
3, 2Pole switching relay
4, Contact: DPDT
5, 250#Quick connect termination
6, Quick connect termination
7, Various of mounting posibtions.
8, Thermal relay is used for overload protection of motor or other electrical equipment and electrical circuits. Used on heat pumps, vending machines, fans, and heating and air conditioning.
Technical parameter:
1, Voltage : DC 6-120V, AC 6-227V
2, Contact Arrangement: 1A, 1B,1C,1A+1B
4, Coil Power: DC type: 2.1w ; AC type: 3.5VA
5, Max Switching Current : 18A
6, Max Switching Voltage : 250VAC
7,Rated voltage: the thermal relay can work normally the highest voltage value, generally for the exchange of 380V, 220V, 600V.
8,Rated current: the rated current of the thermal relay is mainly defined by the current of the thermal relay
45~62HZ.
9,Rated frequency: Generally speaking, its rated frequency according to 45~62HZ design.
10,Setting current range: the range of the setting current is determined by its own characteristics. It is described that the action time of the thermal relay under certain current conditions is inversely proportional to the square of the current.
Characteristics:
| Insulation Resistance | 500MΩ max.(at 500VDC)
| Vibration Resistance | 10Hz to 55Hz 0.5mm DA |
| Dielectric Strength | Between Coil& Contacts | 2500VAC 1min | Ambient Temperature | -40ºC
to 65ºC
|
| Between Open Contact | 1000VAC 1mim | Humidity
| 5% to 85% RH |
| Operate Time(at Nomil.Volt) | DC type:25ms Max | Termination | QC |
| Release Time(At Nomil.Volt) | DC type :25ms MAX | Unit Weight | Approx. 74g |
| Temperature Rese(at Nomil.Volt.) | 90K Max | Construction | Dust protected |
| Shock Resistance(functional) | 98m/s² 11ms | Notes: The data shown above are initial values |
