(GN24-12D) Indoor AC High Voltage Disconnect Switch

Name: (GN24-12D) Indoor AC High Voltage Disconnect Switch
Brand: all-electronics-online.com
SKU: 690786585
Availability: InStock
Rating: 5 (47 reviews)

Price:	Negotiable/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Set
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

GN24-12D Indoor AC High Voltage Disconnect Switch

1. GN24-12(D) disconnect switch is an indoor electric apparatus of rated voltage 12kV, three-phase AC 50/60Hz which is used to make, break and transfer between lines under situations with voltage and no-load.
2. The innovative structure which the disconnector is also fabricated with an earthing switch.
3. The switch also can be mounted through the wall.
4. Reasonable and scientific design, innovative structure
5. Contacting points distribute on two planes, small operation moment, strong pressure release capability, easy adjustment.
6. Improved driving and conducting parts.
Conditions of Use
1. Altitude :1000m,
2. ambient air temperature : not higher than +40 °C, not lower than -25 °C,
3. Relative humidity: daily average of not more than 90% , month average less than 90%,
4. No fire , explosion, corrosion of metal , insulation damage harmful gases and conductive dust place.

Main Features :

1. Reasonable and scientific design, innovative structure.
2. Contacting points distribute on two planes, small operation moment, strong pressure release capability, easy adjustment.
3. Improved driving and conducting parts.

TECHNICAL SPECIFICATION

Size(mm) Current Model	400A 630A				1000A				1250A				Mounting hole spacing mm
Size(mm) Current Model	A	B	C	D	A	B	C	D	A	B	C	D	700*300
GN24-12DI	890	660	450	125	890	690	480	125	890	700	500	125
GN24-12DII	890	660	450	125	890	690	480	125	890	700	500	125
GN24-12DI	890	660	450	240	890	690	480	350	890	700	500	350
GN24-12DIIC	890	660	450	240	890	690	480	350	890	700	500	350
GN24-12DI	920	780	450	125	920	790	480	125	920	790	500	125
GN24-12DIC	920	780	450	240	920	790	480	350	920	790	500	350

Prod Model:	GN24-12D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Indoor:	Three Pahse
Type:	High-voltage
Structure:	Three-column Disconnector
Installation:	Indoor High-voltage
Operation:	Manual
Grounding:	Single Ground
Series:	Three
Run:	Turn the Horizontal
Switching Mode:	Double-Throw Type
Certification:	ISO
Common Model:	Gn6
Brand:	Haivol

Haivo Electrical Co., Ltd, is a provider of power equipment and services for the global electric utility industry. It mainly manufacture power transmission & distribution equipments, covering many product series as Fuse cutout, Surge arrester, Composite & Porcelain insulator, Disconnector switch & Load Break Switch, Hardware fitting for overhead line, Cable accessories and Cable kits (cold & heat shrinkable cable accessories).

HAIVO ELECTRICAL, As one of the international electrical companies in China, We not only manufacture the power equipment, but also provide sustainable power solutions underpinned by technology innovation. To date, HAIVO conducts business in nearly 50 countries and territories in South America, Europe, Latin America, Asia, Africa, and the Middle East. HAIVO′ S high standards have received due recognition from the local power customers.

HAIVO′ S worldwide operation and sales coverage is backed by exceptional experience and expertise to provide customers with the most reliable and highest quality products and services available.

For the quality control system, HAIVO was successively awarded ISO 9001: 2008 by DAS CERTIFICATION Ltd & UKAS QUALITY MANAGEMENT, and TYPE TEST REPORT by China NATIONAL HIGH VOLTAGE APPARATUS QUALITY SUPERVISION TESTING CENTER(XIHARI) & QUALITY INSPECITION AND TEST CENTER FOR EQUIPMENT OF ELECTRIC POWER.

We promise we will offer first-class quality, reasonable price, first-class service and following the business philosophy of development and innovation to serve global power customers!
