Grade B Steel 3 Leg Ange Bar Tray Telecom Tower
| Price: |
US $ 999-1099/Ton |
| Min Order: |
1/Ton |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Grade B Steel 3 Leg Ange Bar Tray Telecom Tower
Specification:
Design |
1. Design Criteria | TIA/EIA-222-G/F |
2. Design Wind Speed | Up to 250 km/h |
3. Allowable deflection | 0.5 ~1.0 degree @ operational speed |
| |
Structure Steel |
| High Tensile Steel | Mild Steel |
4. Grade | GB/T1591:Q345B, Q345C,Q3455D | GB/T 700:Q235B, Q235C,Q235D |
EN10025: S355JR, S355J0,S355J2 | EN10025: S235JR, S235J0,S235J2 |
ASTM A572 Gr50 | ASTM A36 |
5. Tension strength (Mpa) | 470~630 | 360~510 |
6. Yield strength (t≤16mm) (Mpa) | 235 | 355 |
7. Elongation (%) | 24 | 20 |
8. Impact strength KV (J) | 27(20°C)---Q345B(S355JR) | 27(20°C)---Q235B(S235JR) |
27(0°C)---Q345C(S355J0) | 27(0°C)---Q235C(S235J0) |
27(-20°C)---Q345D(S355J2) | 27(-20°C)---Q235D(S235J2) |
Bolts & Nuts |
9. Grade | Grade 4.8, 6.8, 8.8 |
10. Standards for mechanical properties |
10.1 Bolts | ISO 898-1 |
10.2 Nuts | ISO 898-2 |
10.3 Washers | ISO 6507-1 |
11. Standards for Dimensions |
11.1 Bolts | DIN7990, DIN931, DIN933 |
11.2 Nuts | ISO4032, ISO4034 |
11.3 Washers | DIN7989, DIN127B, ISO7091 |
| |
Marking |
12. Method of marking of the members | Hydraulic Press Stamping |
Welding |
13. Method | CO2 Shielded Arc Welding & Submerged Arc Welding(SAW) |
14. Standard | AWS D1.1 |
Galvanizing |
15. Galvanization standard of steel sections | ISO 1461 or ASTM A123 |
16. Galvanization standard of bolts and nuts | ISO 1461 or ASTM A153 |
Capacity |
17. Maximum Production Capacity of Steel Tower per annum | 100,000 TON per annum |
18. Maximum Capacity of Galvanizing Plant per annum | 100,000 TON per annum |
Test |
19. Factory test | Tensile test,Elements analysis, Sharpy test(impact test), Cold Bending, Preece test, Hammer test |
Standards
Bespoke Telecom tower could be fabricated as per GB, EN or ASTM standard with high quality.
Quality control
100% inspection: Each member will be checked by our QC team to ensure all members are qualified before delivery.
Packaging
Set-wisely packing or member-wisely packing as per client's requirements.
Tower members: One steel tower is separated into several bundles.
Bolts: Packing material is robust nylon bag or steel drum
Experiences
Our products have been exported to Philippines, India, Indonesia, Russia, Nigeria, South Africa, UAE and Bahrain etc for 40 countries.
Related Production:Power Transmission Line Tower
Communication Tower
Substation Steel Structure
Flare Tower
LSAW Steel Pipe
Our Project>>.Ethiopian 400kv substation
>>.Macao University of Science&Technolofy Stadium
>>.The China Petroleum University Gymnasium
>>.Wuhan Qiantai Theater
>>.The Stadium Of Zibo City
>>.Huizhou Stadium
Quality Test:Before put into production, all the material must pass the chemical and physical analysis to make sure that they have met the requested strength and component. we have more than 15 inspection procedures from incoming raw material to finished products.
Before shipment, we have a final inspector manager to check the products on every detail and component to make sure it all meet the drawing.
Company Advantage:1. The company has advanced digital physical and chemical laboratory.
2. We have one 3000 tons CNC bending machine, have two domestic advanced digital automatic production line for steel pipe tower, have 6 automatic numerical control robot welding system, havetwo Steel tube joint welding machine , have 4 CNC plasma flame cutting machine, have 6 High
speed CNC Angle steel line and steel plate production line, one CNC tower foot welding robot system. ,2 CNC Plane drilling machine,1 sand shot blasting machine, 1 gantry type submerged arc
welding machine.6 cutting/shearing machine
3. Annual production capacity of 200, 00 tons of hot galvanizing line and one Automatic centrifugal bolt galvanizing line.
Delivery Period :(1) Less than 100ton: Within 1 Months after receiving the advance payment. (2) 100ton ~ 300ton: Within 2 Months after receiving the advance payment.
(3) 300ton ~ 600ton: Within 3 Months after receiving the advance payment.
(4) 600ton ~ 1500ton: Within 4 Months after receiving the advance payment. Why Choose us? * Tower Design tailor made to your requirements
* Pre Dispatch inspection by buyer or international inspection agency.
* Steel certified as per international.
* Design of Tower as per China/ International design standards.
* Galvanization as per international standard.
* Timely project completion.
* Convenient transportation to Qingdao port & airport(only one hour)
* We are manufacturer. We have our own land & factory. The land was bought instead of rent.
* Independent import & export authorization from government.
* Price is competitive
| Prod Model: |
LS-T11 |
| Name: |
Grade B Steel 3 Leg Ange Bar Tray Telecom Tower |
| Material: |
Q235 Q345 Q390 Q420 Gr65 |
| Avaivable Height: |
5-100m |
| Galvanized: |
Hot DIP Galvanization |
| Voltage: |
10kv 35kv 110kv 220kv 500kv 750kv |
| Wind Pressure: |
5-180 Km/H |
| Antenna Support Quantity: |
3-18 PCS |
| Design Free: |
Yes |
| Payment Way: |
30% Down Payment |
| Lifespan: |
50 Years |
| Usage: |
Branching Tower |
| Conductor Circuit: |
Multi Circuit |
| Certification: |
GS |
| Materials: |
Steel |
| Standard: |
Standard |
| Style: |
Independence Tower |
| Structure: |
M Type |
