Specifications
The V60 is a more compact-design and higher-performance GNSS RTK system, besides its rugged design to resist impact and vibration. The V60 has industrial OLED display screen on its front control panel to show all information and status of the work.
Key features
1) BD970 GNSS engine
2) Support GPS, GLONASS, BDS, GALLILEO
3) Large data storage
Detail advantage functions1 Smart Operation:1) Visual LED screen and voice assistance guide your field operation quickly
2) Multi one-button operations. Auto base setup by one button without controller
3) Standard Rinex data and HI-TARGET raw data recorded at the same time
4) Quick upgrade by USB2 Multi-constellation Tracking:1) 220 tracking channels
2) Supports GPS, GLONASS, GALILEO, BDS, SBAS
3) NGS approved GNSS antenna3 Optional Transceiver UHF Radio:1) The transceiver UHF radio enables the working mode to be switchable between base and rover
2) 2-watt HI-TARGET internal UHF radio and 1-watt Satel internal UHF radio are optional.Satel internal UHF radio is compatible with other radios.4 Seamlessly Operation in CORS System:1) Built-in cellular makes V60 work perfectly with network RTK positioning5 Powerful Battery:1) Powered by high-capacity (5000mAh) Li-ion battery to insure whole day operation6 Rugged Design, IP67:1) IP67 dust/water protection
2) Withstands 3-meter natural fall onto concrete| V60 Technical Parameters |
| 220 channels:Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology | GPS:L1C/A, L2C, L2E, L5 |
| GLONASS:L1C/A, L1P, L2C/A (GLONASS M only), L2P |
| BDS: B1, B2 |
| GALILEO:L1 BOC, E5A, E5B, E5AltBOC |
| SBAS: Simultaneous L1 C/A, L5 |
| Module technology | Trimble GNSS MaxwellTM advanced custom measurement technology, |
| GNSS carrier phase measurements of very low noise, |
| precision of 1 Hz bandwidth of <1mm, |
| mature Trimble low elevation tracking technology |
| Positioning Output | 1Hz, 2Hz, 5Hz, 10Hz, 20Hz, 50Hz |
| Differential support | sCMRx, CMR, CMR +, RTCM2.1,2.2,2.3,3.0,3.1 |
| Output format support | ASCLL: NMEA-0183, and binary: Trimble GSOF |
| Data storage | 1GB Internal storage + 8GB Internal Micro SD Card memory
Record GNS and Rinex format simultaneously |
| Performance Specifications |
| Real Time Kinematics (RTK) | Horizontal: 8mm+1ppm RMS |
| Vertical: 20mm+1ppm RMS |
| Initialization time: typically<8s |
| Initialization reliability: typically >99.9% |
| Post Processing Static | Horizontal: 2.5mm+0.5ppm RMS |
| Vertical: 5mm+0.5ppm RMS |
| Post Processing Kinematics(PPK) | Horizontal: 1cm+1ppm RMS |
| Vertical: 2.5cm+1ppm RMS |
| Communications |
| RS232 serial port | x2 |
| Bluetooth, NFC | x1 |
| Integrated GSM/GPRS or 3G modem | x1 |
| TNC antenna connector | x1 |
| DC power intput (8pins&5 pins) | x2 |
| USB standard 2.0 port | x1 |
| Hi-target internal UHFradio(Standard) | 450-470 Mhz, 116 channels, 1w,2w,5w adjustable. work distance: 5-10KM |
| Hi-target external UHF radio(Standard) | Hi-target External radio: 460Mhz,116 channels. 5w, 10w, 20w, 30w adjustable, work distance:8-20km |
| Pacific Crest internal/external UHF radio(optional) | Internal: 403-473Mhz, 3-10KM; External: 390-430Mhz or 430-470Mhz, 8-20KM(work range) |
| Features and Indicators |
| Operation buttons | one power button, one function key |
| Indicators | one satellite indicator (highlighted green), |
| one status indicator (highlighted red and green), |
| one power indicator (highlighted in red). |
| Physical |
| Dimension | 18.20cm x 9.80cm (7.17inch x 3.86inch) |
| Battery | 2*5000mAh, 7.4V |
| Material | The shell is made of environmentally friendly materials Universal Nano |
| Weight | 1.25kg (2.76lb) without internal battery |
| Water and Dust Proof | IP67 ,protected from temporary immersion to depth of 1m (3.28ft). |
| Shock and vibration | Designed to survive a 3m(9.84ft) natural fall onto concrete. |
| External power input | 6V to 28V DC |
| Working temperature: | -45 ºC ~ 65 ºC |
| Storage temperature: | -55 ºC ~ 85 ºC |
Handheld Specifications:| Model | iHand20 | Qmini MP |
| System Configuration | OS | Android 4.2 | Windows mobile 6.5 |
| Processor | MT6589, 1.5GHz, 4core | 806MHz |
| RAM | 1GB | 256MB |
| Flash memory | 4 GB | 8 GB |
| Communication interface | Bluetooth,Mini USB,WIFI:802.11b/g,MicroSD card slot, support up to 32 GB
Dual Sim Dual Standby, support 2G and 3G | Bluetooth,Mini USB,WIFI:802.11b/g,MicroSD card slot, support up to 32 GB,Built-in 3G module |
| Physical | Power | 3.7V, 6300mAh lithium battery, up to 25 hours continuous work | 3.7V, 3100mAh lithium battery, up to 8 hours continuous work |
| Keyboard | Physical keyboard | 10 keys, include the four arrow keys |
| Size | 213mm x 89mm x 35mm | 152mm x 82mm x 32mm |
| Weight | 520g (with battery) | 315g (with battery) |
| Operating temperature | -20ºC to +55ºC | -20ºC to +70ºC |
| Storage temperature | -30ºC to +65ºC | -30ºC to +80ºC |
| Water/dustproof | IP68 | IP65 |
| Anti-shock | 1.2m natural fall | 1.5m natural fall |
Packaging Details
Packing Details:
1 set packed in 3 cartons: 45*40*25cm (7kg),45*40*25cm (7kg), 17*14*145cm(5kg)
Our warranty policy:
1. For instruments (total station,theodolite,GNSS,auto level), we offer 1 year warranty,for accesories(Prism,pole,tripod ,levelling staff).we offer 6 months warranty,from the day you get the product.
2.For product within the warranty period,please send us photos to show the problem.And then we will decide to send you parts or you send the instrument back to us to repair.We will be responsible for the double-run freight and other cost.Please make sure to contact us first instead of sending the damaged parts direct to us.
3.For problem out of the warranty period or warranty liability,we will judge the probelm and quoted for you.You need to pay double-run freight and the maintenace cost.
4.For all instrument we provide life-long technical support.Remark:Improper use of the instrument and man-made damage of the instrument is not coverd in warranty liablity.Warranty only aimed at the problem caused by the product quality.
echnical Specification of Our RTK GPS:
Measurements | 220 channels |
| Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology |
| High precision mulciple correlator for GNSS pesudo range |
| Unfiltered,low noice,low multipath error,low time domine correlation |
| Very low noise GNSS carrier phase measurements with<1mm precision(1 Hz) |
| Signal-to-Noise ratio reprted in dB-Ha |
| Proven Pacific Crest low elevation travking technology |
| Satellite Singnals Tracked | GPS: L1C/A,L2C,L2E,L5 |
| Simultaneously | GLONASS: L1C/A,L1P,L2C/A(GLONASS M only),l2p |
| SBAS: L1 C/A,L5 |
| Galileo: L1 BOC,E5A,E5B,E5ALtBOC |
| BDS/Compass: B1,B2 |
| QZSS: L1 C/A, L1 SAIF,L2C,L5 |
| Positioning performance | Static and Fast Static | Horizonta:l2.5mm+0.5ppm RMS |
| GNSS surveying | Vertica:l5mm+0.5ppm RMS |
| Post Processing Kinematic | Horizontal:1cm+1ppm RMS |
| (PPK/Stop&Go) GNSS surveying | Vertical:2.5cm+1ppm RMS |
| Initialization time:typically 10 minutes |
| For base while 5 minutes for rover |
| Initialization reliability:typically>99.9% |
| Realtime Kinematic(RTK) surveying | Horizontal.8mm+1ppm RMS |
| Vertical.15mm+1ppm RMS |
| Initialization timetypically < 8seconds |
| Initialization reliability.typically > 99.9% |
| Code Differential GNSS postioning | Horizontal.25cm+1ppm RMS |
| Vertical.50cm+1ppm RMS |
| SABS:0.50m Horizontal, 0.85m Vertical |
| Hardware | Physical | Dimensions(W × H):18.20cm×9.80cm(7.17 in.×3.86 in.) |
| Weight:1.25kgs(2.76lbs)without internal battery |
| Operating:-45°C to+65°C(-49°F to+149°F) |
| Storage temperature.-55°C to+85°C(-67°F to+185°F) |
| Humidity:100%,considering |
| Water/dustproof.IP67 dustproof,protected from |
| Temporary immersion to depth of 1 m(3.28ft) |
| Shock and Vibration.Designed to survive |
| a 3m(9.84ft) nature fall onto contrete. |
| Electrical | Power 6V to 28V DC external power input |
| Power consumption ≤3.5w |
| Automatic Switching between internal power and external power |
| Rechargeable, removable 7.4V,5000mAh Lithium-Ion |
| Battery in internal battery compartment |
| Internal battery life | Static 13-15 hours |
| RTK Rover(UHF/GPRS/3G)10-12 hours |
| RTK Base 8-10 hours |
| I/O interface | 1×Bluetooth |
| 1×standard USB2.0 port |
| 1×TNC UHF connector |
| 2×RS232 serial port |
| 2×DC power input(8-pin & 5-pin) |
| 1×Micro SD card port |
| Communication and data storage | 3G Communication | Fully integrated, fully sealed internal 3G, |
| compatabile with GPRS |
| Network RTK(via CORS) range 20-50km |
| HI-TRAGERT internal UHF radio(standard) | Frequency:450~470MHz with 116 channel |
| Transmitting Power:1W,2W,5W,adjustable |
| Transmitting Speed:9.6Kbps,19.2Kbps |
| Working Range:5km typical,8-10km optimal |
| Pacticic Crest XDL Micro internal UHF RADIO | Frequency:403-473MHz |
| Transmitting Power:0.5W,2W adjustable |
| Transmitting Speed:Up to 19.2Kbps |
| Working Range:3-5km typical,8-10km optimal |
| Hi-Target external UHF radio(standard) | Frequency:460MHz with 116 channels |
| Transmitting Power:5W,10W,20W,30W adjustable |
| Transmitting Speed:Up to 19.2Kbps |
| Working Range:8-10km typical,15-20km optimal |
| Pacific Crest ADL vantage Pro External UHF radio | Frequency:390-430MHz or 430-470MHz |
| Transmitting Power:4W to 35W adjustable |
| Transmitting Speed:Up to 19.2Kbps |
| Working Range:8-10km typical,15-20km optimal |
| Support other external Communication device | For example, external GSM moderm. |
|
| Data formats | CMR:sCMRx,CMR, CMR+ input and output |
| RTCM:RTCM2.1 2.2 2.3 3.0 3.1 3.2 input and output |
| Navigation outputs ASCII:NMEA-0183 |
| Navigation outputs Binary:GSOF |
| 1 Pules Per Second Output |
