High Frequency Filter Coil Inductor
| Price: |
US $ 0.15-0.2/Piece |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T |
Basic InfoModel NO.: XP-1062-001
Brand: XP PowerCore Type: Toroidal Q Factor: 2 Magnetic liquid: Air Core Working Frequency: High Frequency Features 1. Separated windings for minimum interwinding capacitance2. Single layer windings for highest common mode impedance over the widest frequency range3. Suitable for 50Hz to 500 KHz4. Spacer provides 1-3mm creepage distance for UL, CSA, IEC compliance5. All materials used are UL94-VO recognized Application Low Frequency AC Reactor, Solar Power System, Power Conditioning System,Wind Power System, Automatic Drive Machine, Induction Heater, Welding Machine, Paper Industries, RFI Suppression Choke, DC/DC converters, IP and OP devices. Electrical Specifications | Part NO. | Inductance(mH)
@1 KHz | IDC(A)
(Max) | DCR(mΩ)
(Max) | Mounting | Dimension(mm)
Coil size A×B×C |
| 220-65-23.5 | 0.065 | 23.5 | 0.9 | Vertical | 26×26×18 |
| 220--100-19 |
0.100 | 19.0 | 1.3 | Vertical | 28×26×18 |
| 220-180-15 | 0.180 | 15.0 | 2.5 | Vertical | 28×26×20 |
| 220-470-12 | 0.470 | 12.0 | 4.0 | Vertical | 28×26×18 |
| 220-880-9 | 0.880 | 9.0 | 6.5 | Horizontal | 28×30×20 |
| 220-1000-3.2 | 1.000 | 3.2 | 15.3 | Vertical | 26×26×17 |
| 220-1180-7.5 | 1.180 | 7.5 | 12.5 | Horizontal | 26×28×20 |
| 220-1500-2 | 1.500 | 2.0 | 18.0 | Vertical | 26×26×18 |
| 220-1800-5 | 1.800 | 5.0 | 50.0 | Horizontal | 26×28×18 |
| 220-2200-5 | 2.200 | 5.0 | 40.0 | Vertical | 26×26×19 |
| 250-200-15 | 0.200 | 15.0 | 5.0 | Horizontal | 30×28×15 |
| 250-200-18 | 0.200 | 18.0 | 5.0 | Vertical | 30×28×15 |
| 250-300-15 | 0.300 | 15.0 | 7.3 | Horizontal | 30×32×18 |
| 250-300-15A | 0.300 | 15.0 | 7.3 | Vertical | 38×28×17 |
| 250-425-8 | 0.425 | 8.0 | 4.26 | Vertical | 32×30×21 |
| 250-600-9 | 0.600 | 9.0 | 10.0 | Horizontal | 30×30×18 |
| 250-600-9A | 0.600 | 9.0 | 10.0 | Vertical | 30×28×19 |
| 250-1000-8 | 1.000 | 8.0 | 20.0 | Vertical | 30×28×13 |
| 250-3500-1.5 | 3.500 | 1.5 | 80.0 | Horizontal | 30×32×16 |
| 250-3700-4 | 3.700 | 4.0 | 70.0 | Vertical | 30×32×17 |
We can design and manufacture customized part with specific requirement. Reasons of our top-quality components help your business succeed:- 22 years of experience customizing and power transformers
- Your professional and reliable partner for various electronics
- Over 1000 buyers value our products
- 20000m2 factory with 21 production lines and 800 employees
- 5 million units annual capacity
- Our Products has the UL Insulation System, Quality is guaranteed
- High quality and best services
- More models and types are available. Welcome your spec and sample to make custom-manufacturing.
| Prod Model: |
XP-1062-001 |
| Type: |
Choke Inductor |
| Structure: |
Inductive Choke |
| Brand: |
XP Power |
XP Power that was established in 1992 is a manufacturing, integrating research & development, trading company, supply as a whole. The company is one of the world's leading developers and manufacturers of power transformers, power inductors, choke coils, high frequency transformers and reactors solutions for the electronics industry with specialists who are versed in all the technical and legislation requirements. The products of XP Power are stable quality, full range of variety, prompt delivery, competitive price so that they are applicable in new energy, communication facilities, UPS power, household appliances, Medical instrument, monitor, automotive electronics and so many other fields. After over a dozen of years' development, the company has complete quality management system, scientific technology research and development system and good service team. And now XP Power has fixed assets to the value of USD 60 million and six hundred employees and three factories located in Foshan, Hefei and Xi' An. The company has an annual production capacity of 50 million PCS. Our main market is Europe, North & South America, Middle East and Asia.
The company is equipped with advanced manufacturing equipment and testing apparatus as well as a R&D center comprised by various technicians, which can offer different customers different new products according to customers' needs, developing and researching more new projects. Our company always adheres to the high quality and technological innovation. In the process of production the rigorous quality inspection standards and inspection technique are used in order to realize the total quality management from the incoming inspection, process inspection, to the outgoing inspection, which guarantee the high quality. The quality of our products recognizes by some authorities and gets all sorts of world-class certification, such as ISO9001 and ISO14001, etc. Our products are RoHS and REACH compliant.
XP Power supplies its products to 30 countries across the globe. Every year, over 30 million coils are wound, over 20 million high frequency transformers are manufactured, and thousands of modules are mounted.
