| Prod Model: |
DP to HDMI cable (DP-H) |
| Plating: |
24K Gold or Nickel |
| Length: |
1.5m, 2m, 3m, 5m, 8m, 10m, 12m, 15m |
| Conductor: |
Oxygen Free Copper |
| Conductor Number: |
20pin |
| Jacket: |
PVC |
| Flame Rating: |
VW-1 |
| Warranty: |
5 Years |
| UL Standard: |
Awm 20276 |
| Certify: |
UL RoHS Reach |
| Standard: |
RoHS, Ce, ISO9001, UL, CCC |
| Application: |
Game Player |
| Color: |
Black |
| Type: |
Twisted Pair |
| Certification: |
VDE |
| Connector: |
Dp to HDMI |
| Species: |
Displayport to HDMI Cable |
| Brand: |
Fulsan |
Product Description
High Quality 1080P 4K Displayport DP to HDMI Adapter Cable 0.5M/1M/1.5M/1.8M/3M/5M
Displayport to HDMI Cable
Male to Male 1.8M, 3m
100% Pure Copper conductor
24K Gold-Plated Connector with Dust cap
Compliant with DisplayPort Interoperability specification V1.1a.
. Support full DisplayPort link training.
. Compliant with HDMI 1.3a specification up to 2.25 Gbps.
. ESD protect: Human Body Mode at 8 kV, Machine Mode at 400V, and Charged Device Mode at 2 kV.
. PC: VGA, SVGA, XGA, SXGA, and UXGA.
. HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p.
. Standby mode current: 64uA...LED indicator: Cable link status.
. W/Latch, W/LED, Adapter Type, Plastic Cover Ass'y, Width=21mm, RoHS
This is a DisplayPort to HDMI Adapter for interfacing next generation DisplayPort based PC and notebook computers with high definition displays. DisplayPort offers a unified, scalable, and cost effective interface for embedded and external display applications. As desktop and notebook PCs are increasingly transitioning from conventional analog type interfaces to DisplayPort, the converter facilitates the transition by offering seamless connectivity between new DisplayPort PC and the installed base HDMI monitors and projectors.
It offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
Electrical:
100% open and short test
Voltage: 300V DC, 5MΩ /10ms
Insulation resistance: 10MΩ Minimum
Contact resistance: 2Ω Maximum
Working temperature: -25 to 80 degree Celsius
| Item | High Speed HDMI to Displayport Cable |
| Connector | Full 19pin HDMI port 24k gold plated |
| Connector type | Type A |
| Plug mould | PVC injection mould, bi-color mould, metal shell mould |
| Gender | Male |
| conductor | Full oxygen-free pure copper |
| Wire gauge | AWG24, AWG26, AWG28, AWG30 |
| Cable jacket | PVC |
| Support | 1080P, 3D, ethernet, 4K, audio return channel |
| Application | HDTV, DVD player, set top box, xbox360, ps3, satellite, home studio^ |
| Packing | 1. Polybag, blister packaging etc |
| | 2.According to customers. |
