High Quality 70mm2 Copper Conductor Welding Cable for Indonesia Market

SPECIFICATION
high quality flexile welding cables are suitable for dry and wet Indoor and outdoor usage.

Nominal cross-section   (mm2)	Nominal sheath thickness (mm)	Average of the max. outer diameter (mm)	No./Dia  of stranding   (mm)	conductor resistance at 20°C (≤Ω/km)	Weight   (kg/km)
10	1.8	9.7	332/0.20	1.91	151.6
16	2.0	11.5	513/0.20	1.61	224
25	2.0	13	798/0.20	0.758	326
35	2.0	14.5	1121/0.20	0.536	430
50	2.2	17	1596/0.20	0.379	600
70	2.4	19.5	2214/0.20	0.268	818.1
95	2.6	22	2997/0.20	0.198	1082.7

1.Specific property for using

 1.1. The cable can be used in the connectors of electric weld and pliers of the electrical welding
whose toward earth voltage of the low voltage is not more than AC 200V and the pulsating DC peak value is 400V.
 1.2. The long term permissible working temperature of cable conductive core is not more than 65°C.

Applicant
   The cables are suitable for power plant, various household appliances, power tools and various portable electrical equipments
with rated voltage Uo/U of 450/750V and below.

PACKING
steel reel,gunny bag,etc





COMPANY INFORMATION
Jiaxing Huahao Cable Co., Ltd., is located in Haiyan Economic Developing Zone, Zhejiang Province. We are at the north of Hangzhou Bay Bridge, 100km away from Shanghai Pudong Airport, 50 minutes away from Hangzhou International Airport by car. The superior geographical surrounding and speedy transportation network provide us a great convenience for goods transportation at home and abroad. Since the establishment in 2010, we have been specialized in designing, developing, and producing all kinds of PVC cable materials, injection materials, environmental protection materials, such as welding cables, speaker cables, and audio cables. All products are subjected to the most advanced testing equipment by virtue of strong human resources, technical support and production strength.

Welcome to visit our cable factory and we are expecting to cooperate with all kinds of cable importers, wholesaler &retail trader from all over the world as well as double-win with our partners and build long-time business relationship. Since the establishment, we have implemented the business philosophy"QUALITY FIRST, CUSTOMER FIRST, HONEST FIRST. "That is our presistent persuit to offer you excellent service and quality
guarantee.

FAQ

Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
