High Quality G657A1 FTTH Drop Cable

Name: High Quality G657A1 FTTH Drop Cable
Brand: all-electronics-online.com
SKU: 828190335
Availability: InStock
Rating: 4.6 (124 reviews)

Price:	US $ 49KM
Min Order:	100KM
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Ftth Drop Cable
1. Special curved optical fiber, providing greater bandwidth and enhanced network transmission characteristics.
2. Two parallel fiber optic cable, FRP has a good compression performance, can protect the fiber.
3. Cable structure is simple, light weight, strong practical.
4. Unique groove design, easy peeling, convenience for connect, and simplify installation and maintenance;
LSZH jackets, environmental protection and safety.
5. The struture of indoor optical FTTH cable: In the centre is the optical communication unit, with the parallel non-metical enhanced FRP of the two side. The sheath materiar can be LSZH or PVC.

1. Fiber Parameters

No.	Items			Unit	Specification
					G.657A1
1	Mode Field Diameter		1310nm	μm	8.6±0.4
			1550nm	μm	9.6±0.5
2	Cladding Diameter			μm	125.0±0.7
3	Cladding Non-Circularity			%	≤0.7
4	/ Core-Cladding Concentricity Error			μm	≤0.5
5	Coating Diameter			μm	245±5
6	Coating Non-Circularity			%	≤6.0
7	/ Cladding-Coating Concentricity Error			μm	<12.0
8	Cable Cutoff Wavelength			nm	λcc≤1260
9	Attenuation (max.)		1310nm	dB/km	≤0.35
			1550nm	dB/km	≤0.20
10	Macro-Bending Loss	1 turn×7.5mm radius @1550nm		dB	≤0.4
		1 turn×7.5mm radius @1625nm		dB	≤0.8

2. Cable Parameters

Items		Specifications
Fiber Count		1
Colored Coating Fiber	Dimension	250±15μm
Colored Coating Fiber	Color	Blue
Strength Member	Dimension	0.5mm
Strength Member	Material	FRP
Self-Supporting Member	Dimension	1.2mm
Self-Supporting Member	Material	Steel
Jacket	Dimension	5.0±0.2mm×2.2±0.2mm
	Material	LSZH
	Color	Black

3. Mechanical and Environmental Characteristics

Items	Unite	Specifications
() Tension(Long Term)	N	300
() Tension(Short Term)	N	600
() Crush(Long Term)	N/10cm	1000
() Crush(Short Term)	N/10cm	2200
() Min. Bend Radius(Dynamic)	mm	20D
()Min. Bend Radius(Static)	mm	10D
Installation Temperature	ºC	-20~+60
Operating Temperature	ºC	-40~+70
Storage Temperature	ºC	-40~+70

Prod Model:	GJYXCH
Application:	Communication
Type:	Single-mode Fiber
Certification:	CE
Connection Structure:	Fast Connector or Splice
Sheath Material:	LSZH

HIGHVISION is a high-tech company specialized in design, developing, manufacture and marketing Telecommunication products, like Optica fiber Cables, Optical Passive Devices, ODN products and as well as transmission equipments and CATV products with international advanced technology.

With high experienced R&D engineers and professional QA team, we supply to our clients all over the world with high standard products but competitive prices.

Our prodcut range covers as below:

All kinds of Optic Fiber Cables, indoor or out door,

Optic Patch Cords and Pigtails,

Armored Jumper Cables for FTTA, aks CPRI cables,

Optic Passives like PLC Splitters, xDWN Modules, Optic Switches,

ODN Products such as Terminal Box, Fiber Distribution Box, Fiber Splice Closure, etc

Optic Transsmission items like xSFP, Optic Node, EDFA, etc.

And testing & Installtion instruments and accessories.
