High Quality Intelligent Light Sensor and Time Controlled Remote Controller

Name: High Quality Intelligent Light Sensor and Time Controlled Remote Controller
Brand: all-electronics-online.com
SKU: 802295975
Availability: InStock
Rating: 4.6 (33 reviews)

Price:	US $ 9.25-9.3/Piece
Min Order:	100/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	LYD-LK-TIME
Connection Mode:	Common Anode
Static Power Consumption:	<1W
Output Current:	<4A(Each Circuit)
Net Weight:	180g
Controller's Dimension:	1227125mm
Application:	Audio / Video Players
Signal Transmission:	IR Remote Control
Type:	Button
Certification:	CE
Universal:	Universal
Transmission Distance:	50-100m
Battery Type:	Button Battery
Voltage:	DC5V, 12V~24voptional
Material:	Aluminum

Product Description

Basic Info

Place of Origin:	Guangdong, China (Mainland)	Brand Name:	louita	Model Number:	LYD-LK-TIME
Type:	Manual Switch	Max. Load Power:	12V≤144W;24V≤288W	Voltage:	DC12-24V
Name:	LED Time Controller Programmable	Supply Voltage:	DC12-24V	Connecting mode:	common anode
Output:	3 channel	Output Current:	<4A(each channel)	Output power:	12V≤144W;24V≤288W
static power consumption:	<1W	External dimension:	L122W71H25 mm	Working Temperature:	-20-60°C
Certification:	CE & RoHS

Product Description
The controller is adopted 8 digital tube to show the modes of time and work. It adopts PWM dimmer electric.It matches the precise clock clip which can control the brightness and darkness of the light according to the time .When present time is same as the predicted time , the light will change as previous brightness. You can set 5 scenes during the 24 hours one day. By optional sensor, the controller can autocatalytically adjust the brightness fo the light according to the brightness and darkness of the environment optical line.The controller can be used for the normal one.The controller works through the infrared remote controller, and operate easily.

Technical Parmeters

Work temperature	-20-60°C
Supply voltage	DC12-24V
0utput	3 channel
connecting mode	common anode
Output current	<4A(each channel)
Static consumption	<0.24W
Output power	12V≤144W;24V≤288W
PWM signal class	256 level
PWM signal frequency	325HZ
Remote Control distance	>10M
Time deviation	<5 seconds per month
Controller Size	L122W71H25 mm
packing size	L135W80H55 mm
Net weight	180g
Gross weight	210g

Packaging&Shipping

With advantage of many years producing LED in large scale as well as advanced technicians in lamp manufacturing field. LYD entered into the lamp market which uses LED as its lamp-house, as a high-tech enterprise which specialize in producing out door&indoor decorative lighting products.

Our company's main products are: Book Lights, Flexible LED Strips, Rigid LED Strips, LED Module, LED Controller, Power Supply. Our products have been widely used in illumination, advertisement, city enlightening projects, traffic lamp, decorating, electronic gifts and toys, and many other production fields.

Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.

Through persevering efforts, we have become one of the largest suppliers in LED light field in China and also won the trust of our customers because of excellent quality and prompt delivery.

Choosing louita means choosing satisfaction and choosing benefit! We firmly believe "Technology changes the world and the world will be more brilliant because of louita"
