High Voltage Composite Suspension Post Insulator
| Price: |
US $ 5.99-8.99/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
FXBW-24-70&FZSW-25/5 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Maximum Voltage: |
20kv~100kv |
| Chemistry: |
Organic Insulation |
| Thermal Rating: |
200 200 |
| Material: |
Composite Polymer |
| Application: |
Insulators |
| Structure: |
Sunpension & Post |
| Type: |
Solid |
| Brand: |
Zhon |
| Color: |
Grey |
| Certification: |
Cnas ,Cnal |
Product Description
Composite Suspension Insulator & Composite Post Insulator
Characteristics:
-Small volume and light weight, easy to transport and install
-The superior in performance and high intensity mechanical enhance reliability of power line
-Extraordinary hydrophobic and resistance to contamination
-Long-duration resistance aging and leakage tracking
KEMA, CNAS, CNAL,ROHS ISO9001 certificates
FAQ:
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: How long are you company manufacture the products?
A: We are established in 2003 year.
3. Q: How can I get some samples?
A: We are honored to offer you samples.
4. Q: How does your factory do regarding quality control?
A: Quality is priority. ZHON people always attach great importance to quality controlling from the very beginning to the very end.
|
Product Model |
Rated voltage (kV) |
Rated mechanical bending load (kN) |
Structure height
(mm) |
Min. arcing distance
(mm) |
Min. nominal creepage distance (mm) |
Uimp wts (peak)
(kV) |
Uw. 1min wts (peak)
(kV) |
|
FXBW-24/70 |
24 |
70 |
450 |
235 |
635 |
150 |
65 |
|
FZSW-24/70 |
25 |
5 |
380 |
320 |
750 |
150 |
65 |
Zhejiang Zhongneng Electrical Co., Ltd., located in Zhejiang Province, is the key medium/high voltage electric productive enterprise of FATO Mechanical and Electrical Equipment Group Co., Ltd.And a provincial advanced enterprise, mainly producing 220kV and below high voltage electro ceramic products, especially lightning arrester series, composite insulator series and drop-out fuse cutout series, and low-voltage surge protective device series.Our products have complete testing devices and strict quality and production management systems.Our products are known for the characteristics of solid power, advanced science and technology, considering service and solid quality.Moreover, for some core products, we have the independent intellectual property right.
Our corporation has the independent corporate capacity.Our progenitor is the division store of Suzhou Surge Arrester Co., Ltd.Which is founded in 1989, and after joined into FATO Mechanical and Electrical Equipment Group Co., Ltd.In 2003, we changed the name to Zhejiang Zhongneng Electrical Co., Ltd.
Zhejiang Zhongneng Electrical Co., Ltd.Is the professional over-voltage protectors manufacturing enterprise, and a member unit of China Electric Industry Association.We passed the certification of ISO9001 quality system and confirmed to standards such as IEC 60099-4, 61643-1, 291, 282 issued by international electric and industrial committee.Moreover, we have a long-term technical cooperation with many technical and research institutes and core enterprises in this industry line, and the qualities of our products can stand long-time decimation.
Following the technical and economical developing step, and the globalization process, in the merger process of global advantage resources, we constantly expect the cooperation coming from global partner.We are looking forward to cooperating with you!
