High Voltage H. R. C. Current Limiting Fuse For Transformer Protection

Technical specification:
1, Rated voltage: 7.2kv-40.5kv
2, Wide range of rated current: 6.3A-200A
3, Full range performance options available at 12kv and 24kv
4, Powerful pyrotechnic or spring striker
5, H. R. C
6, Current-limiting
7, Low power dissipation, low temperature rise
8, Operation extremely quickly, high reliability
9, With primary coil of transformer in series
10, Isolating & protecting transformer
11, Conforming to standards: DIN43625 BS2692-1 IEC60282-1

Basic parameters

Type	Rated Voltage(KV)	Rated current(A)	Rated brake current(KA)	Dimensions(mm)
XRNPl-/-*-1	7.2(3.6)12	0.2,0.3,0.5,1,2,3.15	50	Drawing 1
XRNPl-/-*-1	24	0.2, 0.3,0.5,1,2,3.15	50	Drawing 2
XRNPl-/-*-2	12	2,3.15	50	Drawing 3
XRNP6-/-*-1	40.5	0.2,0.3,0.5,1,2,3.15	31.5	Drawing 4(Φ25)
XRNP6-/-*-3		0.2,0.3,0.5,1,2,3.15 4,5		Drawing 5(Φ30)
XRNP6-/-*-4		0.2,0.5,1,2,3.15,5,6.3		Drawing 6(Φ41)

Prod Model:	XRNT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Operation:	Manual Type
Installation:	Open Frame
Speed:	High-Speed Circuit Breaker
Structure:	Moulded Case Circuit Breaker
Arc-Extinguishing Medium:	Air
Function:	HRC
Certification:	ISO9001-2000
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	High Voltage
