Hot sale 3000W UPS solar power charge inverter
Product DescriptionProduct characteristic1,POWERBOOM series of intelligent high-power belt charging
2,UPS function inverter power supply (inverter), high-performance power output, easy to use, connected to the car cigarette lighter or battery, you can DC12V or DC24V DC power supply, AC220V or AC110V AC power output, so that your car can also have home AC power, in the car to enjoy the convenience of home appliances and mobile business office.For your car equipment:Notebook computers, digital cameras, cell phone chargers, lighting fixtures, power tools, printers, fax machines, electric shavers, camcorders, audio, DVD players, televisions, electric fans, refrigerators, etc.Electrical equipment to provide a stable and reliable AC power.And high power with charge
3,UPS function inverter power supply high peak output, high load, with battery charging function, can drive large-scale electrical equipment, the most suitable for home, industrial, marine, communications, military and other fields;Is your family emergency, Driving out of travel, wild camping, mobile office good companion
Product FeaturesSolar Inverter with Charger:
1. Fixed sine wave output
2. Instantaneous power up to 1000 W
3. Efficiency up to 92%
4. Intelligent control of the cooling fan function
5. Protection of various types:Battery low voltage shutdown / output short circuit / overload / overvoltage / over temperature / battery low voltage alarmCharger:
1. Maximum charge current 6A
2. 80% efficiency
3. Mains input overload protection
4. Anti-voltage, lightning strike
5. Charging mode:3-stage charging method (constant current, constant voltage, floating charge)Product Parameters| Model | PB-3000C |
| Inverter Output | Rated Power(Typ.) | 3000W | 3000W |
|
| | AC Voltage | 220V | 220V |
| | Frequency | 50HZ±0.5HZ | 50HZ±0.5HZ |
| | Waveform | Square Wave under rated power(THD<3%) | Square Wave under rated power(THD<3%) |
| Inverter Input | Battery Voltage | 12V | 24V |
|
| | Voltage Range(Typ.) | 10V-15V | 20V-30V |
| | DC Current(Typ.) | 185A | 92A |
| | Load Loss | ≤0.3A | ≤0.2A |
| | Shutdown mode current | ≤20mA | ≤20mA |
| | Max Efficiency(Typ.) | ≥90% | ≥90% |
| | Battery Type | Lead Acid Battery | Lead Acid Battery |
| Battery Output Protection | fuse | 35A*8 | 35A*4 |
| | Battery Low Voltage Alarm | 10.5V±0.5V | 20V±1V |
| | Battery low voltage shutdown | 9.5V±0.5V | 19V±1V |
| | Battery high voltage protection | 15.5V±0.5V | 30V±1V |
| | Battery reverse protection | Through internal insured | Through internal insured |
| Output Protection | Over Temperature | 75ºC±5ºC | 75ºC±5ºC |
| | | Bright red light, with alarm sound, no output | Bright red light, with alarm sound, no output |
| | Output Short Circuit | Traffic lights alternately flash, cancel the short circuit automatically return to normal | Traffic lights alternately flash, cancel the short circuit automatically return to normal |
| | Over Load(Typ.) | ≥ 2000W | ≥ 2000W |
| | | Bright red light, self-locking, reduce load restart to return to normal output | Bright red light, self-locking, reduce load restart to return to normal output |
| Charge Input | Rated Voltage | 220V | 220V |
| | Rated Efficiency | 50/60HZ±0.5HZ | 50/60HZ±0.5HZ |
| | Rated Efficiency | ≥80% | ≥80% |
| Charger Method | The output voltage is three-stage charging | Constant current charging current 15A charging indicator is orange | Constant current charging current 8A charging indicator is orange |
|
| | | Constant voltage charging voltage 14.4V charging indicator is orange | Constant voltage charging voltage 28.8V charging indicator is orange |
| | | Floating charge voltage 13.5V Charging indicator is green | Floating charge voltage 27V Charging indicator is green |
| Charge Input Protection | fuse | 5A*1 | 5A*1 |
| | Over Load | 8A overcurrent protector | 8A overcurrent protector |
| | Mains overvoltage / lightning strikes | Varistor | Varistor |
| Output Protection | Short Temperature Protection | 35A*1 | 15A*1 |
| | Time to turn on electricity | Yes | Yes |
| | Output Voltage | Through internal insured | Through internal insured |
| USB | Output Current | ≤20mS | ≤20mS |
| | Operating Temperature | ≤20mS | ≤20mS |
| USB | Operating Humidity | 5V |
| | Storage Tmperature and Humidity | 2A |
| Enviroenment | Operating Temperature | 0-40ºC |
| | Operating Humidity | 10-90%RH,No Cold Storage |
| | Storage Tmperature and Humidity | 20ºC~60ºC 5-95%RH |
| Others | Weight | Net:4.4 Kg Gross:5.6 Kg |
| | Size | 384*180*142 mm(L*W*H) |
| | Packing | 434*242*202 mm(L*W*H) |
| Remarks | Unless otherwise specified, all specifications are measured at 25 ° C ambient temperature. |
