Insulation Piercing Connectors(IPC)
Our company keep eye on the electric connection field, the IPC is our new products. Now we have 20 items of IPC series, general apply to branch power cable connection in the main cable range is 4 sq. Mm to 300 sq. Mm, the branch cable range is 1.5 sq. Mm to 240 sq. Mm.
IPC application.
1, For main to main connection and widely apply to T & secondary connections in distribution system, the connection of airy & underground low voltage insulated cable in metering and street lighting.
2, Application: Widely apply to T & secondary connections in distribution system, the connection of airy & underground low voltage insulated cable in metering and street lighting.
|
Type |
Main line section
(mm²) |
Branch
section(mm²) |
Norminal current(A) |
Bolt |
Piercing depth |
|
mm² |
AWG |
mm² |
AWG |
Quantity |
H(Nm) |
1.0-1.5 |
|
JCF1-6/6 |
0.75-6 |
18-8 |
0.75-6 |
18-8 |
41 |
1XM6 |
---- |
1.5-2.0 |
|
JCF1-35/4 |
4-35 |
12-2 |
1.5-10 |
16-7 |
86 |
1XM8 |
H13(9Nm) |
1.0-2.0 |
|
JCF1-35/6 |
6-35 |
8-2 |
1.5-10 |
16-7 |
86 |
1XM8 |
H13(9Nm) |
1.5-2.0 |
|
JCF1-95/10 |
16-95 |
5-4/0 |
1.5-10 |
16-7 |
86 |
1XM8 |
H13(9Nm) |
1.0-2.0 |
|
JCF1-50/35 |
6-50 |
8-1/0 |
6-35 |
8-2 |
200 |
1XM8 |
H13(9Nm) |
1.0-2.0 |
|
JCF1-95/25 |
25-95 |
3-4/0 |
2.5-25 |
13-3 |
161 |
1XM8 |
H13(9Nm) |
1.5-2.0 |
|
JCF1-95/35 |
25-95 |
3-4/0 |
(2.5)6-35 |
(13)8-2 |
200 |
1XM8 |
H13(14Nm) |
1.5-2.5 |
|
JCF1-95/95 |
25-95 |
3-4/0 |
25-95 |
3-4/0 |
377 |
1XM8 |
H13(18Nm) |
1.5-2.5 |
|
JCF1-150-150 |
35-150 |
2-300 |
35-150 |
2-300 |
504 |
1XM8 |
H13(18Nm) |
1.5-2.5 |
|
JCF1-120/120 |
35-120 |
2-250 |
35-120 |
2-250 |
437 |
1XM8 |
H13(18Nm) |
1.5-2.5 |
|
JCF1-150/95 |
50-150 |
1/0-300 |
25-95 |
3-4/0 |
504 |
1XM8 |
H13(18Nm) |
1.5-2.5 |
|
JCF1-185/35 |
50-185 |
1/0-400 |
(2.5)6-35 |
(13)8-2 |
200 |
1XM8 |
H13(14Nm) |
1.5-2.5 |
|
JCF1-100/100 |
60-100 |
1/0-4/0 |
60-100 |
1/0-4/0 |
377 |
2XM8 |
H13(14Nm) |
1.5-2.5 |
|
JCF1-95/95B |
25-95 |
3-4/0 |
25-95 |
3-4/0 |
377 |
2XM8 |
H13(14Nm) |
1.5-2.5 |
|
JCF1-185/150 |
50-185 |
1/0-400 |
50-150 |
1/0-300 |
504 |
2XM8 |
H13(18Nm) |
1.5-2.5 |
|
JCF1-240/95 |
70-240 |
2/0-00000 |
16-95 |
5-4/0 |
377 |
2X10M |
H13(20Nm) |
1.5-2.5 |
|
JCF1-240/240 |
95-240 |
4/0-00000 |
95-240 |
4/0-00000 |
504 |
2X10M |
H13(25Nm) |
1.5-2.5 |
|
JCF1-380/240 |
120-380 |
250-00000 |
95-240 |
4/0-00000 |
679 |
2X10M |
H13(37Nm) |
1.5-2.5 |
