LMR 195 Coaxial Cable Made in China
| Price: |
US $ 0.05-2.0/Meter |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10000/Meter |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
1. Description of LMR 195 Coaxial Cable Made in China
* LMR 195 CoaxialCables
* Inner Conductor:0.94mm
* Dielectric:2.79mm
* First Shield:2.95mm
* SecondShield:3.53mm
* Jacket:4.95mm
* Packing:100M or 305M Wood Spool
2. Electrical Characteristics
| Item |
| Impedance(Ω) | 50±2 |
| Capacitance(pF/m) | 83.30 |
| Velocity of Propagation(%) | 80.00 |
| Min Screening Effectiveness(dB) | >=90 |
| Inner Conductor DCR(Ohm/km) | 24.90 |
| Outer Shield DCR(Ohm/km) | 16.10 |
| Voltage Withstand(Volts DC) | 1000.00 |
| Spark Test(VRMS) | 3000.00 |
| Installation Temp Range(ºC) | -40ºC~70ºC |
| Operating Temp Range(ºC) | -40ºC~70ºC |
3. Attenuation (@20%)
Max Attenuation(dB/100m) | Frequency |
| 50MHz | 8.4 |
| 150MHz | 14.6 |
| 220MHz | 17.7 |
| 450MHz | 25.5 |
| 900MHz | 36.5 |
| 1500MHz | 47.7 |
| 1800MHz | 52.5 |
| 2000MHz | 55.4 |
| 2500MHz | 62.4 |
| 5800MHz | 98.1 |
VSWR |
VSWR Max | 800~2500MHz | 1.20 |
| 100~480MHz | 1.15 |
| 800~1900MHz | 1.15 |
| 1900~2500MHz | 1.18 |
4. FAQ
Q1: What's the MOQ, can i buy 1 piece the first time?
Re:The MOQ of LMR Coaxial Cable is 10KM.
Q2: What's delivery time?
Re: The general delivery time is 4-6days after order confirmed, it depends on the order quantity
Q3: Can you send me a free sample?
Re: We are willing to send you free sample, if you would like to pay the shipping costs
Q4: What's your payment terms?
Re: 30% in advance, and 70% before shipment
Q5: What's the payment method?
Re: We accept T/T, Western Union, L/C
Q6: How to ship the items to me?
Re: Courier (DHL, TNT, FEDEX, UPS, EMS), Airfreight, Ocean Ship are available.
| Prod Model: |
LMR195 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Inner Conductor: |
0.94mm |
| Dielectric: |
2.79mm |
| First Shield: |
2.95mm |
| Secondshield: |
3.53mm |
| Jacket: |
4.95mm |
| Impedance: |
50ohm |
| Capacitance: |
83.30(Pf/M) |
| Velocity Of Propagation: |
80.00(%) |
| Installation Temp Range: |
-40ºC~70ºC |
| Operating Temp Range: |
-40ºC~70ºC |
| Application: |
Coaxial Cable |
| Certification: |
UL |
| Brand: |
Daytai/ OEM |
| Conductor Material: |
Bc/ CCS |
| Type: |
Coaxial Cable |
| Cover Material: |
PVC/ PE |
