Low Voltage Service Bakelite Cut out Fuse Protection 60A

Name: Low Voltage Service Bakelite Cut out Fuse Protection 60A
Brand: all-electronics-online.com
SKU: 829893175
Availability: InStock
Rating: 4.3 (133 reviews)

Price:	Negotiable/Piece
Min Order:	200/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Raw Material:	Bakelite, Porcelain, Brass
Color:	Black
Product Type:	Current Fuse
Form Of Installation:	Insurance Tube Holder
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	Low Voltage
Shape:	Square
Standard:	UK

Product Description

Malaysia LUCY 60A/ 63A Bakelite Fuse Cutout

APPLICATION :
1.This cut out are made of high grade phenolic moulding powder having high mechanical and dielectric strength.
2.The body possesser non-hygroscopic and non-tracking qualities.
3.Terminal contacts are of tinned brass with phosphor bronze back up compression spring capable of providing flawless service even after years of use.
4.It has features like: All components are inter-locked. Sealing provision to avoid unauthorized access. Common body from 15amps to 100amps.
5.Terminal are suitable for aluminium/copper conductors upto 35sq. mm loop in and loop out cabling contacts available.
6.The Insulated service cut out conform to BS 1361-1986 standard SRH fuses conform to BS1361.1986. The available current is 60# 60/80A, 100# 60/80A, 100# 100A, 100# 1P+N 60/80A, 100# 1P+N 100A.

Type	Raw material	Max Current	Voltage
Lucy	Bakelite, Porcelain, Brass	60A,100A	250V
